Battery Charging - Stocker 242 Benutzerhandbuch

6
how to mount the carrying straps
1. Fix the clip at the upper end of the strap to the hook at sprayer's base.
1
how to mount the spray lance
A
A
60
Electric Backpack Sprayer 15 l
Assembly
B
B
Art. 242 Art. 242
Electric Backpack Sprayer 15 l
Usage
be charged only by plugging the charger's plug into the charging socket without being removed
from the sprayer. If the charging indicator lamp turns green, it indicates that the battery has
been fully charged.
C
lowest working voltage of the sprayer is DC 10,5~10,8 V. The charger shall be operated indoors
at a dry, well-ventilated and safe place over 50 cm above the ground. If the sprayer has been
used for a short time, it is unnecessary to charge. If it has been laid aside for a long time, it shall
be fully discharged before being fully charged with a regular interval (such as one month or two
C
months) in a bid to maintain the capacity and service life of the battery.
For further information about the product, please contact info@stockergarden.com.
Sign up to our newsletter and keep up to date with our latest news info@stockergarden.com

Battery charging

Make sure that the input parameters of charger comply with
the AC parameters of mains supply. If not, please contact the
distributor. The battery of sprayer has been fully charged before
being delivered. Due to self-discharge during transportation and
storage, you shall check the power level with the voltage meter
before operation. If the indicator stays in yellow or red area,
(i.e.≤12V), a supplementary charging is required. The battery can
Voltmeter
The sprayer is equipped with a high-precision voltmeter measu-
ring voltage of 11V - 15V. The green area of color scale indica-
tes full battery, fit for normal operation; yellow area indicates
insufficient voltage but the system can still keep working; the red
area on the left indicates extremely low power requiring imme-
diate recharging. The graduation and value above the color scale
indicate the percent of residual power against the full power. The
7
61
