Unpacking and checking equipment
Welcome to use two-way radio. Carefully unpack the radio. We recommend you check the
items listed in the following table before discarding the package If any item is missing
please contact local dealer immediately

Supplied accessories

Li-on battery (1)
Charger (1)
Belt Clip (1)
User's Manual (1)

Getting familiar

Antenna
Speaker
sound output
Microphone
Sound input
PTT switch
Press it to transmit,
release to receive
Power/ volume knob
Indicator light
It turns red in transmitting,
and turns green in receiving.
It blinks red when the battery
capscity is low.
Mic/speaker jack/
programming port
Used to connect headset
or external programming
cable, programmable via
PC programming software
Li-ion battery
For supplying power to
radio
