Serial Numbers - Peg Perego kit auto Gebrauchsanleitung

through the slot in the mattress pad (fig_a) and the slots
in the shell (fig_b) so that they come out on the other side
(fig_c).
4• Pass the two ends of the shoulder straps through the slots
in the mattress pad and the shell (fig_a), then clip them to
the pins (fig_b).
5• Straps attached under the shell (fig_a) and inside the Car
bassinet unit (fig_b).
attachment in vehicles with safety belts
ATTACHING THE BASSINET UNIT IN VEHICLES: It is possible to
install the bassinet unit in cars if there are 3 rear seats with 3
safety belts. The central one can be 3-point or a lap belt.
We recommend positioning the bassinet unit on the
vehicle's rear seats with the end for the child's head above
the central seat.
6• Car bassinet unit fitted in a vehicle with a lap belt.
7• Car bassinet unit fitted in a vehicle with a 3-point belt.
8• The Car bassinet unit can also be positioned in the centre
of a 3-person rear seat, using the two outer safety belts
(fig_a). It cannot be positioned as in fig_b because it can
only be secured in vehicles using safety belts that come
from opposite sides.
9• Position of the Car bassinet unit on a 2-person rear seat.
The Car bassinet unit can be positioned with the child's
feet on either side of the vehicle. If the seat of the vehicle
inclines, towels can be used to provide a horizontal surface.
1 0• Take the safety belt of the vehicle's rear seat located at the
end with the child's feet, fold it (fig_a) and insert it in the slot
of one of the two straps provided (fig_b). Insert the red bar
on the strap into the loop of the folded safety belt (fig_c).
1 1• Press the grey lever on the left (fig_a) and attach the strap
to the ring on the Car bassinet unit (fig_b).
• Repeat the procedure with the belt located at the end of
the bassinet unit for the child's head.
1 2• Once the strap is fastened to the ring of the Car bassinet
unit, tighten the safety belt to ensure the bassinet unit is
properly secured in the vehicle. Pull the safety belt towards
you (arrow_a), hold it still and tighten it from the back of
the strap (arrow_b) to secure it.
1 3• Strap fastened to the safety belt and the bassinet unit at
the feet end (fig_a). Strap fastened to the safety belt and
the bassinet unit at the head end (fig_b).
1 4• Car bassinet unit installed in vehicles.
1 5• RELEASING THE BASSINET UNIT FROM VEHICLES: Press the
grey lever on the strap (fig_a) and remove it from the rings
on the two sides of the bassinet unit (fig_b). If one of the
two straps is too tight and difficult to loosen, press on the
bassinet unit as you release the strap.
how to put the child in the Car bassinet
unit
1 6• 3-POINT SAFETY HARNESS: Slacken the straps by pressing
on the buckle (fig_a) and lengthen them (fig_b).
1 7• Press the red button (fig_a) and release the straps from the
leg divider (fig_b).
1 8• Place the child in the Car bassinet unit then buckle
together the straps and the leg divider.
1 9• The child must be securely fastened in the Car bassinet
unit. If the straps are loose, tighten them by pulling on the
end.
The straps must be as tight as possible to protect the child
in the event of an accident. Leave a minimal amount of
play (the width of a finger between the harness and the
child's chest).
2 0• REMOVE THE STRAPS: To remove the straps from the shell
of the Car bassinet unit, pass the buckles of the leg divider
through the slots under the shell and pull them through
(fig_a). To remove the strap fasteners from under the shell,
release them from the clips and pass them through the
slots (fig_b).
2 1• Put the harness back in its pocket once it has been removed.
serial numbers
2 2• Information about the production date of Car bassinet unit
can be found under the base.
• Product name, production date and serial number (fig_a).
Car Kit:
• Approval label (fig_b).
• Harness production date (fig_c).
In the event of problems with the product, these details
15
