3. To maintain the easy adjustability of the hand-
lebar post, the handlebar post should be cleaned
and lubricated. First, turn the front adjustment knob
counterclockwise and slide the handlebar post out
of the frame. Apply a small amount of lubricant
spray to a lint-free cloth, and clean the handlebar
post (A).
Next, reinsert the handlebar post into the frame
and adjust it to the desired height. Loosen
the front lock handle and slide the handlebar
carriage as far back as possible. Apply a small
amount of lubricant spray to a lint-free cloth, and
clean the surface of the handlebar slide (B). Then
slide the handlebar carriage as far forward as
possible and clean the top of the handlebar slide.
Finally, adjust the handlebar to the desired position.

Monthly maintenance:

1. To maintain the smooth function of the height
adjustment knobs
saddle, the metal
ment knobs (A) must be lubricated. Use
of white lithium
G
Version 1.1 2013 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2013
for the handlebar
threads on the
grease is recommended.
PREVENTATIVE MAINTENANCE
3
B
A
1
and
adjust-
|
www.indoorcycling.com
(
A
G (2 : 5)
ENG 15
