Saddle horizontal adjustment:
Proper horizontal adjustment of the saddle is very important in avoiding injury to the knees.
Sit on the saddle and move the pedals until the crank arms are in horizontal position.
Using your forward leg as a marker, your kneecap should be directly above the
center of the pedal so that a straight line is created between knee and center of the pedal
(see the dotted line in image below). To adjust the horizontal position of the saddle, first
dismount the TOMAHAWK IC3 Indoor Cycle. Next, loosen the rear lever handle, slide the
saddle forward or backward as required, and then retighten the lever handle.
horizontal adjustment
with lever handle
Version 1.1 2013 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2013
HOW TO ADJUST THE TOMAHAWK IC3 Indoor Cycle
|
