14:
Crotch strap position adjustment:
Disconnect crotch strap clip from under seat (1).
Push the crotch strap clip through seat (2)
Re-position in alternative slot (3).
Seat liner:
15:
The seat liner contains a wedge (1).
When your child weighs under 4 kg, the child car seat must be used WITH the seat
liner and wedge.
When your child weighs between 4.1 and 13 kg, the child car seat can be used with
the seat liner WITHOUT the wedge.
Handle:
16:
Adjusting:
17:
Handle positions:
(1) Carrying position
Location:
18: IMPORTANT: Never use the child car seat on a seat where an
airbag is fitted and active. Refer to your vehicle user manual for
information on de-activating the airbag.
WARNING: Your child car seat can only be installed rearward
facing using a three point lap and diagonal vehicle belt in the
front or rear passenger seats of the car.
Fitting:
19:
Adjust the handle to carrying position
Position the child car seat on the vehicle seat, pass the vehicle waist belt through the
side vehicle belt guides (2) and fasten the vehicle belt buckle(3).
Route the diagonal belt under handle hinge (4) then through rear vehicle seat belt
guide (5).
Tension the diagonal belt (6).
IMPORTANT: The position of the vehicle belt buckle can affect the
stability of the child car seat. In an accident this could stop
the child car seat from protecting your child as well as it should.
After tightening the vehicle belt, if the buckle lies in the position
marked then try fitting the child car seat in another seating
position in your vehicle. If in doubt, consult either the child car
seat manufacturer or retailer.
Removing softgoods:
20:
Loosen the harness
Disconnect shoulder straps from harness connector (2).
Pull shoulder straps out of seat (3) and chest pads (4).
Push crotch strap clip through seat (5).
Remove harness (6).
(2) Stow position
16 17
7 (1).
(3) Steady position
(1).
