Fitting & Operation Information:
Please refer to the following diagrams:
Preparation:
1:
Using a ball point pen push in the button on the hood bar (1) then pull the hood
bar out of its receiver.
Noting the orientation of the hood bar, Fit the hood fabric over the hood bar (2).
2:
Noting the orientation of the hood bar, refit the hood bar (1).
NOTE: The dots on the hood bar and hood bar receiver should be
matching (2).
Attach the poppers(3).
3:
Fit the seat liner behind the harnes (1).
Hood:
4:
Opening:
5:
Closing:
6:
Removing:
Unfasten the poppers (1).
Using a ball point pen push in the button on the arm (2) then pull the arm out of the
hinge unit (3).
Pull the arms out of the hood fabric (4).
Harness:
7:
Loosening:
NOTE: Pull only the harness straps.
8:
Tightening:
NOTE: The harness must be reasonably tight. It should restrain
but not make the child uncomfortable.
Check that the straps are not twisted while the child is seated.
9:
Opening:
10:
Closing:
Adjusting the shoulder strap position:
11:
Loosen harness
Disconnect the shoulder straps from the harness connector (2).
12:
Pull shoulder strap out of seat (1) and refit at desired position (2).
Reconnect the shoulder straps to the harness connector (3).
Tighten harness
13:
Satisfactory shoulder strap position:
Check satisfactory chest pad position.
