Set-up
5.1
C/K setting
Power Factor Regulator
+0,93 PF/ MANUAL
123---
4" Setup
Puss 4 seconds for aut. functioning
Power Factor Regulator
SETUP
3 C/K
+0,97 PF
Blinking
4" Setup
The suggested value to set is given on the table.
Use the
or
buttons to change the
selection.
Power 1
C/K
T.A. - C.T.
5
6
10
12,5
30/5
5
5
-
-
50/5
3
4
5
-
60/5
3
4
5
5
80/5
3
3
5
5
100/5
3
3
3
4
150/5
2
3
3
3
200/5
2
2
3
3
250/5
2
2
3
3
300/5
2
2
2
3
400/5
2
2
2
2
500/5
1
2
2
2
600/5
1
1
2
2
800/5
1
1
2
2
1000/5
1
1
1
2
1200/5
1
1
1
1
1500/
1
1
1
1
2000/5
1
1
1
1
2500/5
1
1
1
1
3000/5
1
1
1
1
4000/5
1
1
1
1
When the CT secondary current signal is
lower than 2 amps, the C/K value should
be increased by 0,1.
When using the regulator on 220Vac
networks the C/K values should be doubled.
"-" means installation of C.T. with primary
value too small.
38
st
bank (kvar)
20
25
40
50
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
5
-
-
-
5
5
-
-
3
4
5
-
3
3
5
5
3
3
4
5
3
3
3
4
3
3
3
3
2
3
3
3
2
2
3
3
2
2
3
3
2
2
2
3
2
2
2
2
1
1
2
2
1
1
2
2
1
1
2
2
1
2
1
1
