OJ GreenZone™ Master
Symptom
Unable to log into the web server of the OJ
GreenZone™ Master via the Router/DHCP
LAN-connection
Unable to log into the web server of the OJ
GreenZone™ Master via smartphone.
One or more OJ GreenZone™ Modules are
lacking in the web server
One or more OJ GreenZone™ Modules are
lacking in the web server
No alarm is generated when digital input 1
is activated
Function: The input detects alarms from
the inlet fan
No alarm is generated when digital input 2
is activated
Function: The input detects alarms from the
exhaust fan
Cause
The IP address in the OJ GreenZone™
Master is set to "Static"
LAN cables connected incorrectly
The IP address in the PC network card is
set to "Static"
Incorrect IP address in address line
Defective PC network card
Defective OJ GreenZone™ Master
The Wi-Fi router is switched off
The smartphone is not connected to the
Wi-Fi network
Incorrect IP address in address line
One or more OJ GreenZone™ Modules
lack power
Fault in the Modbus cable connection
between OJ GreenZone™ Master and OJ
GreenZone™ Modules or between succes-
sive OJ GreenZone™ Modules
Defective OJ GreenZone™ Module
Defective OJ GreenZone™ Master
Fault in the electrical connection
Fault in the electrical connection
Action
Set the IP address to "DHCP" by means of the built-in web server or using the IPconfig utility.
Check all LAN cable connections in the router, PC and OJ GreenZone™ Master.
Set the IP address to "Obtain an IP address automatically".
Enter the correct IP address in the web browser: 192.168.1.101.
Try again with another PC.
Replace OJ GreenZone™ Master.
Switch on the Wi-Fi router.
Search for available networks on your smartphone.
Connect the smartphone to the same network to which the OJ GreenZone™ Master is connected.
Start a web browser on your smartphone and enter the correct IP address in the web browser.
OJ GreenZone™ Master's IP address is read out by means of the IPconfig utility.
Check the power supply to the OJ GreenZone™ Modules.
Correct power connection to an OJ GreenZone™ Module is illustrated in figs 8 and 9 of the OJ Green-
Zone™ Module instructions.
Check the Modbus cable connection between the OJ GreenZone™ Master and OJ GreenZone™ Mod-
ules and between successive OJ GreenZone™ Modules.
Replace OJ GreenZone™ Module.
Replace OJ GreenZone™ Master.
Check the electrical connection. See fig. 11.
The alarm should be triggered when the input is activated (On).
Check the electrical connection. See fig. 11.
The alarm should be triggered when the input is activated (On).
