LIST OF FIGURES

The following figures are located at the back of the instructions:
Fig. 1: OJ GreenZone™ Master
Fig. 2: Dimensions, front view
Fig. 3: Dimensions, side view
Fig. 4: Overview of connectors in OJ GreenZone™ Master
Fig. 5: Analogue outputs, 0-10 VDC
Fig. 6: Digital outputs (Dou1 and Dou2)
Fig. 7: Digital outputs (Dou3, Dou4 and Dou5)
Fig. 8: RJ12 Modbus connector: Modbus Out1, Modbus Out2, Cascade In
Fig. 9: Modbus cable connection
Fig. 10: Connecting the power supply
Fig. 11: Digital inputs (Din1...Din6)
Fig. 12: Connecting PT1000 sensors
Fig. 13: SD card reader
Fig. 14: TCP/IP BMS, Modbus AHU, Cascade Out
Fig. 15: Modbus Out1, Modbus Out2 and Cascade In
Fig. 16: Electrical Modbus cascade configuration
Fig. 17: Connector position overview
Fig. 18: Connecting OJ GreenZone™ Modules
Fig. 19: Configuration overview
Fig. 20: Communication configuration
Fig. 21: KNX configuration
Fig. 22: Electrical connection when the AHU enables the zones
Fig. 23: Electrical connection when the zones initiate the AHU
Fig. 24: RJ12 Modbus connector: Modbus AHU and Cascade Out
Fig. 25: Modbus connection to OJ-Air2 Master
Fig. 26: Modbus connection to third party AHU
Fig. 27: Configuration - Demand Controlled Ventilation
Fig. 28: Configuration - Common extract
Fig. 29: Configuration - Branch VAV
Fig. 30: Configuration - Pressure protection
Fig. 31: Configuration - Slave in large room
Fig. 32 : Configuration - How to set the adress?
INTRODUCTION
OJ GreenZone™ Master is an electronic controller capable of controlling up to 25
VAV zones in a ventilation system. OJ GreenZone™ Master contains all the func-
tions necessary to control up to 25 zones by means of OJ GreenZone™ Module. A
maximum of five OJ GreenZone™ Masters can be connected in a fully expanded
system. A fully expanded OJ GreenZone™ system can thus control up to 125
zones.
DESCRIPTION
OJ GreenZone™ Master is the "intelligent" component in an OJ GreenZone™
system, while OJ GreenZone™ Modules simply control individual zones/rooms. OJ
GreenZone™ Master and the connected Green Zone Modules are configured by
means of the built-in web server.
OJ GreenZone™ Master contains a sophisticated function which optimises the
control of fan speed and of the hot and/or cold water pump.
The control and comfort parameters of the OJ GreenZone™ Master can be ac-
cessed either via the built-in web server or by connecting the OJ GreenZone™
system to a Building Management System (BMS) from where it can be operated.
The BMS communication protocol is either Modbus or BACnet. KNX components
within the zones can be connected by means of the KNX/Ethernet converter.
The OJ GreenZone™ Master communicates with the OJ GreenZone™ Modules
in the connected zones by means of standard Modbus RS485. By combining a
maximum of five OJ GreenZone™ Masters in a system where each Master controls
up to twenty-five OJ GreenZone™ Modules, it is possible to control and regulate
125 individual zones/rooms.
