OJ GreenZone™ Master

Resolution, temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.01°C

Voltage outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 x 0-10 VDC

Enclosure rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IP20

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (see figs 2 and 3)

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 430 g

Configuring the OJ GreenZone™ Master

The OJ GreenZone™ Master and connected OJ GreenZone™

Modules are configured by means of the built-in web server. For

information on the web server, please refer to the installer instructions.

The current version of the installer instructions is available at www.

ojelectronics.com.

COMMUNICATION PROTOCOLS

BACnet, TCP/IP to BMS

OJ GreenZone™ Master supports BACnet for TCP/IP communication with a BMS

system. BACnet TCP/IP should be connected to the connector marked TCP/IP

BMS (see fig. 14). The current BACnet protocol is available at OJ Electronics A/S

webpage.

Modbus, TCP/IP to BMS

OJ GreenZone™ Master supports Modbus for TCP/IP communication with a BMS

system. Modbus TCP/IP should be connected to the connector marked TCP/IP

BMS (see fig. 14). The current Modbus protocol is available at OJ Electronics A/S

webpage.

TCP/IP

OJ GreenZone™ Master uses the following standard parameters for TCP/IP net-

work:

IP address:

192.168.1.101

Netmask:

255.255.255.0

Gateway:

192.168.1.1

DNS:

192.168.1.1

Alternative DNS:

0.0.0.0

OJ GreenZone™ Master supports "IPconfig". IPconfig is a PC based utility for set-

ting and reading out TCP/IP network settings for units connected in a LAN network.

IPconfig can scan a LAN network for connected units, and the user can set com-

munication parameters, e.g. IP address, Netmask, Gateway, DNS and host name,

for each individual unit.

IPconfig allows the OJ GreenZone™ Master IP address to be read out and config-

ured.

Only TCP/IP units that support IPconfig can be scanned by IPconfig.

IPconfig can be downloaded from www.ojelectronics.com.

KNX router interface for zone components

OJ GreenZone™ Master supports communication with "KNX IP BAOS 772" KNX router

(make: Weinzierl) via its ObjectServer interface (see figs 20 and 21).

OJ GreenZone™ Master uses the IP address "192.168.1.33" as default IP

address for the KNX router. The current KNX protocol is available at OJ

Electronics A/S webpage.
