3. INSTALLATION

3.2 Installing your cooker

• The cooker may be placed near another piece of furniture, but make sure that the height of
surrounding furniture does not exceed the cooker height (see fig. 5).
• If kitchen furniture are above the cooker, leave a space of at least 10cm between the sides of the
cooker and the furniture.
• The minimum height between the cooktop and the hood (or wall units) is shown in Fig. 5. The
exhaust hood must be located at least 65cm from the cooktop. If there is no hood, the height
between the cooktop and the furniture above
• Leave a 2cm space between the rear of the cooker and the wall, and between the sides and
adjacent furniture.
• Pay attention not to place the cooker near a refrigerator; there must be no flammable or
ignitable materials such as curtain, cloth, etc... that may easily get burnt.
• Adjacent furniture must be manufactured resistant to temperatures up to 100°C.
Extracting
hood
Air inlet section
min. 100cm
2
Figure 3
Min. 60cm
COOKER HOOD
Electrical ventilator
Air inlet section
min. 100cm
must not be less than 70cm
9
2
Figure 4
Figure 5
.
