DMT-10
DIGITAL TEXTMODULE
Technichal Data
Inputs
Outputs
Frequency Response
Operating Voltage
Current Consumption
Sampling Frequency
Ambient Temperature
Memory Size
Audio file format
External Memory Storage
Message Recording Time
Message Backup Time
Dimensions (mm)
Weight (kg)
DMT-10
MIC:
-50dB / 600Ω UNBAL
LINE:
-10dB / 10kΩ UNBAL
Remote Control Inputs: 10 PIN connector (M1~M6, START/STOP, REPEAT/STOP, BUSY)
SD card down load
DCF-77
Audio Output:
-10dB UNBAL
Headphone Output: 24mW≥64Ω
MIC: 150Hz~15kHz
LINE: 50 Hz~15kHz
+15V DC ~ +17V DC
150mA
32 kHz
0°C ~ 50°C
Voice/each 128kb (23 sec)
M1~M6/each 2176kb (360 sec)
mp3 (128kbps – 320 kbps)
microSD-Card (max. 4 GB)
Refer to table
Nonvolatile
194(W) x 40(H) x 85(D)
0,27
11
