Contents
1. Introduction

Safety Information ................................................................ 03

Short description ................................................................... 03

Delivery ........................................................................................ 03
System Components .......................................................... 04
2. Installation
Installation ................................................................................. 05
Gluing instructions ............................................................... 06
Connection ............................................................................... 07
The control unit ...................................................................... 08
Satellite broadcasting ......................................................... 09
Startup and operation ........................................................ 10
Setting the LNB skew .......................................................... 11
3. Troubleshooting ................................................................... 12
4. Skew Settings .......................................................................... 13
5. Firmware Update .................................................................. 14
6. Footprint ..................................................................................... 16
7. Specifications .......................................................................... 17
ENGLISH
02
Safety Information
Caution - Improper handling by unqualified personnel can cause serious
damage to this equipment. Unqualified personnel who tamper with this
equipment may be held liable for any resultant damage to the equipment.
Note - Before you begin, carefully read each of the procedures in this ma-
nual. If you have not performed similar operations on comparable equip-
ment, do not attempt to perform these procedures.
Short description
The satellite antenna system is the innovative and a technologically advanced satellite
Positioner system. The antenna has a unique combination of cutting-edge components.
Fast satellite search and compatibility with all digital, HD-ready set-top boxes and TV sets
are guaranteed.
Delivery
Shipman / Shipmas GPS/AS
• Control unit (IDU) incl. powercable
• 1x antenna cable (10 m)
• 1x antenna cable (1 m)
• Installation glue (optional)
• Power supply 230 V (12 V, 5 A) (optional)
• User manual
