Technical Information

Diagnosis Management

Diagnosis Management

In addition to the ProfiBus six byte standard diagnostic, the interface
provides both user diagnostic and static diagnostics functions.
The Diagnostic Buffer is structured as below:

Standard Diagnostic

The standard diagnostic management is fully compliant with the
ProfiBus specification.

User Diagnostic

During the start-up phase after gateway power on, or controller
power on, the first byte in the user diagnostic area, can assume
values different from zero.
This byte has the following meaning: (offset 6)
Bit 0
166/178
7 bytes standard diagnostic (offset 0 to 6)
User diagnostic:
- 1 byte Interface status (offset 7) common for
- First controller (always present)
* 2 bytes Parametrization Diagnostic
* 5 bytes Output Buffer Diagnostic
- Second controller (if present)
* 2 bytes Parametrization Diagnostic
* 5 bytes Output Buffer Diagnostic
- Third controller (if present)
* 2 bytes Parametrization Diagnostic
* 5 bytes Output Buffer Diagnostic
- Fourth controller (if present)
* 2 bytes Parametrization Diagnostic
* 5 bytes Output Buffer Diagnostic.
1: controller not responds (RS485 link broken)
TMP Profibus Gateway User Manual / 87-900-976-01 (F)
all controllers
