I/O Panel
1
17
No. Description
1 USB 2.0 Ports (USB_1_2)
2 Antenna Ports
3 DisplayPort 1.2
4 USB 3.0 Ports (USB3_1_2)
5 LAN RJ-45 Port*
6 Central / Bass (Orange)
7 Rear Speaker (Black)
8 Line In (Light Blue)
9 Front Speaker (Lime)**
4
2 3
16 15
No. Description
10
11
12
13
14
15
16
17
4 5
14 13 12
Microphone (Pink)
Optical SPDIF Out Port
USB 3.0 Ports (USB3_3_4)
HDMI-In Port
Clear CMOS Switch
HDMI-Out Port
DVI-I Port
PS/2 Mouse/Keyboard Port
6 8
7 9
11 10
