1. Introduction
Frilled Lizard Robot has an infrared sensor that is programmed to "
escape" or "follow-me".
If the infrared sensor is activated in the "escape" mode the robot will
automatically act "shocked!", spreading its frill, dropping its jaw,
illuminates its bicolor LED eyes and will scurry away from you until it
escapes to a safe distance. If the infrared sensor is switched to the "
follow-me" mode using the 2 way function switch, then the robot will
assess danger by bluffing the attacker (unfurling and shaking its frill).
When the robot does not sense danger it will proceed to follow you
like a pet lizard.
2. Tools You May Need
a) Diagonal Cutter
b) Screwdriver
c) Knife
d) Hammer
3. Mechanical Parts List
Warning. This product has sharp functional points and/or edges that
can cause injury if used improperly.)
P1 Pinion Gear(White) x 2
P2 Gear(Red) x 1
P3 Gear(Yellow) x 1
P4 Gear(White) x 1
P5 Gear(Purple) x 1
P6 Gear With Shaft x 1
P7 Tapping Screw x 5
P8 Hex Shaft(S) x 1
P9 Hex Shaft(M) x 1
P10 Hex Shaft L x 1
P11 Round Shaft x 2
P12 Round Shaft x 1
P13 PC Board x 1
P14 Motor With Connector Red / Black Short Wires x 1
P15 Motor With Connector Red / Black Long Wires x 1
P16 Battery Holder With Connector x 1
P17 Battery Holder With Connector x 1
P18 Frill (Spare part : 1 pc) x 1
P19 Adhesive Tape Spare Par x 1
P20 Sticker
x 1
4. Plastic Parts
Cut the plastic parts when they are required.
Do not cut them in advance.
a. Spare Part
Tip: cut off the burrs before assembly
a. burr burr burr
5. Head Module Assembly
5.3.
P2 (Red)
P8 (Short)
5.4.
P14 W / Short Wires
a. Black
b. Red
Side View
5.6.
a. Red
b. Black
5.7.
Make sure " ▼ " to be faced up to you, it is to assist you in assembling
C8 correctly.
5.9.
Make sure adhesive tapes come with thin glued films while tearing
off.
5.10.
Cut the frill as below illustration.
*Includes an extra frill
5.11.
No stickers on the printing side.
The opposite (no printing) side to be faced up.
a. Front
b. Back
5.12.
Pull
Note: Frill is not pictured below to clearly illustrate assembly.
PUSH
5.15.
Push
6. Body Module Assembly
6.1.
P10 (Long)
P5 (Purple)
P3 (Yellow)
6.2.
Do not mix up C4 & C3, make sure C4 for assembly.
Very important!
6.3.
P4 (White)
6.5. P15 W / Long Wires
6.7.
Hammer slightly.
6.8.
P9 (Middle)
Important!
Do not mix up C4 & C3, make sure C3 for assembly.
6.18.
Top View
6.19.
Top View
Note: Make sure that the wheels are not too tight or too loose.
Important!
6.21.
Black
Red
6.23.
Black
Red
6.26.
Side View
6.33.
Finished
7. Stickers
8. How To Play
Neck
Adjustable angle
9. Funway 1
Escape mode
a. Shocked !!
b. Bluffing !
c. Escape
10. Funway 2
Follow-me mode
Bluffing attacker by popping up its frill.
Follow me like a pet.
11. Warning
Be gentle to hold your Lizard Robot, any improper manners (as
below figs) might cause its malfunction
12. Trouble Shooting
1. Ensure all wirings are correct.
2. If the lizard robot does not work, please check if batteries are
placed in correct polarity. Also make sure the connector of battery
compartment plug to PC board no problem.
3. Do not play the Lizard robot under direct sunlight or halogen lamp,
it may cause the robot to go wrong direction.
4. If the lizard robot goes unsmoothly:
4.1. Please check if front wheels are stuck by objects/or dust.
4.2. Check if the ball-joints (A11/A1/A8/A2) of the front /rear legs are
stuck by objects/or dust.
4.3. Make sure C4/C22 are installed tightly.
4.4. Make sure C3/C21 are installed tightly.
