EN
1.0 INSTALLATION
Before installing the battery charger, make sure that:
1.
It is protected from humidity and rain.
2.
It is installed on a stable, safe surface.
3.
There is sufficient space at the back of the charger to ensure good ventila-
tion.
4.
The clamps are not short-circuiting.
5.
The mains cable and the clamp cables are in perfect condition.
1.1
CONNECTING TO THE MAINS.
Check that the mains voltage corresponds with that indicated on the identification
plate fixed to the battery charger (230 V a.c. or 240 V a.c. 50/60 Hz). For the con-
nection, use a three-pole plug (two phases earth) rated at least 10 Amp.
1.2
CONNECTING TO THE BATTERY (PREPARING FOR THE CHARGE).
Before starting to charge the battery, check that the capacity (Ah) of the battery
concerned is within the maximum and minimum Cr values indicated on the identi-
fication plate of your battery charge
a.
Cr max (Ah): maximum battery capacity, chargeable with the maximum
current that can be supplied in 15 hours.
b.
Cr min (Ah): minimum battery capacity, chargeable with the minimum cur-
rent that can be supplied in 4 hours.
1.
With the mains cable being disconnected, insert the negative cable plug in
the output terminal with the voltage that corresponds with the battery to be
charged (12V or 24V depending on the battery).
2.
Connect the battery to the charger: the red cable to the battery's positive
terminal and the black cable to its negative one. First of all, connect the pos-
itive cable to the battery's positive terminal (which is not earthed), then con-
nect the negative cable to the car body, well away from the battery and the
fuel lines.
3.
Plug the unit into the mains socket.
4.
When the battery has been charged, remove the power plug or set the
charger's power switch to "OFF". Then remove the conductor from the car
body and the battery; finally, remove the clamps from the battery.
After use, store the battery charger in a dry place.
NEVER CONNECT OR DISCONNECT THE CLAMPS FROM THE
BATTERY WITH THE BATTERY CHARGER FUNCTIONING. FIRST
SWITCH THE UNIT OFF.
1.3
SIMULTANEOUSLY CHARGING MORE THAN ONE BATTERY.
If you have to charge more than one battery simultaneously, you can connect
them in series or in parallel. Of the two systems, connection in series is prefera-
ble, as in this way you can check that the current in each battery corresponds to
that indicated by the ammeter.
1.4
PROTECTIONS.
The battery charger is fitted with an overload cut-out that intervenes in the event
of:
1.
Over-charging (excessive current supplied to the battery).
2.
Short-circuiting of the charging clamps.
3.
Inversion of polarity on the battery terminals.
Battery chargers with fuses: replace, if necessary, with an identical
fuse having the same rating.
WARNING.
REPLACING THE FUSE WITH ONE HAVING A CURRENT RATING
DIFFERENT FROM THAT INDICATED ON THE IDENTIFICATION
PLATE COULD CAUSE DAMAGE TO PROPERTY OR INJURY TO
PERSONS. FOR THE SAME REASON, YOU SHOULD NEVER
REPLACE THE FUSE WITH COPPER WIRE OR OTHER MAKE-
SHIFT MEANS.
BEFORE CHANGING THE FUSE, DISCONNECT THE POWER CABLE
FROM THE MAINS. IF THIS WARNING IS IGNORED, CEMONT
DECLINES RESPONSIBILITY FOR ANY CONSEQUENCES THAT MAY
RESULT.
1.5
USEFUL TIPS.
1.
To avoid gas building up, always charge batteries in a well-ventilated area.
2.
Before starting charging, take the cap off each element.
3.
Check that the level of liquid inside the battery covers the tops of the plates;
if it does not, top-up with distilled water to the maximum level indicated on
the battery.
4.
The liquid in the battery is highly corrosive, and must not be allowed to
come into contact with the skin.
5.
Clean the positive and negative terminals of any oxide scale, so as to ensure
good contact with the clamps.
6.
Never let the two clamps make contact when the battery charger is con-
nected to the mains.
7.
If the battery with which you intend to use this battery charger is perma-
nently installed in a vehicle, refer to the "ELECTRICAL SYSTEM" or "MAIN-
TENANCE" section/s of the owner's handbook and/or maintenance manual.
Before starting charging, it is advisable to disconnect the positive cable of
the vehicle's electrical system.
8.
Check the battery's voltage before connecting it to the battery charger.
Remember that a 6-Volt battery has three caps and a 12-Volt battery has
six. In some cases, there may be two 12-Volt batteries; if so, you will
require a voltage of 24 Volt to charge both.
9.
Check the polarity of the terminals. The positive terminal is marked "+":
the negative one is marked "-". If these symbols are indistinguishable,
remember that the negative terminal is the one connected directly to the
vehicle's body.
2.0 TECHNICAL SPECIFICATIONS
2.1
DATA PLATE
Single-phase power supplY
Frequency
Starting/charging voltage
Effective charging current
Average charging current
EN 60335-2-29
Max. power absorbed
Rated reference capacity
Dimensions
Weight
Fuses
( EN ) 2
WARNING:
FAST 7
FAST 10
A
230
Hz
50/60
V
12
12-24
A
7
10
A
5
8
KW
0,2
0,2
Ah/15h
90
120
mm
320x230x195 330x230x220
Kg
4
5
1x10A
1x15A
