Steam Mop Operation
1. Attach the mop pad to the holder.
2. To attach the mop pad holder: place the front of the steam
cleaner on the holder, align the foot pedal to the centre
of the head and gently press the head to the holder until
it "snaps" together.
NOTE: Never use the steam mop without the microfiber
steam mop pad in place.
3. For carpet cleaning only, proceed according to step
3 and fit the carpet glider on the head. If the steam
cleaner is used on hard floors, remove the carpet
glider.
4. Grasp the water tank release lever and pull forward
and upward to remove the water tank.
5. Remove the cap from the bottom of the water tank and
fill it with water. Make sure the cap sealing is in its place.
Screw the cap and put the water tank back.
NOTE: Do not attempt to use steam mop with an
empty water tank!
6. Turn the power switch on, (the power indicator will be on).
7. Press the steam level button, to adjust the steam level.
The default is maximum, can be adjusted to minimum.
8. When the MIN/MAX indicator stops flashing (when it
light steadily), press and hold the steam trigger (on the
inner side of the handle) to start steam cleaning.
9. When the Steam Mop stops emitting steam turn the
power OFF and refill the water tank.
10. Steam Settings:
Tiles/Stone - Maximum
Sealed wooden floor - Minimum
NOTE: When the microfiber steam mop pad becomes too
wet or dirty, replace with a clean cloth.
CP 3000
VAC
Steam
EN
VAC
Steam
Steam
trigger
47
