2. InSTALLATIOn AnD ELECTRIC COnnECTIOn
1. Install the extractor fan at least 2,3 m above the floor level.
2. Remove the screw-covers. Separate the cover (1) from the motor housing (2) by removing the screws (3).
3. Insert the motor housing (2) so that it corresponds with the outlet hole, by means of screws and adequate expansion plugs (Fig. 1)
4. For glass-mounted type (Fig. 2): fasten, with the four screws (5) supplied, the motor holder (2) on the flange (4) with the accessory ASPIRkIT
VETRO "G" or "F" already mounted.
5. If connecting with outside wiring, break off one of the two plastic parts (E) of the motor support in order to pass the cable (Fig. 5).
6. Fasten the feed cable by means of a cable-clip and connct to the terminal block (Fig. 3). In case of feed-cable-strap type, overtum the cable-clip.
7. If the input power line is under chase, break off the plastic part (F) of the motor support, in order to pass the wiring (Fig. 5).
8. Insert cover (1) and tighten screws (3). Insert the screw-covers.
ALL MODELS CAn BE FITTED WITh ThE FOLLOWInG ACCESSORIES:
• ASPIRkIT VETRO G10/4" - G12/5" - G15/6":
Accessories for glass mounting of the ASPIRMURO serie.
• ASPIRkIT VETRO F10/4" - F12/5" - F15/6":
Accessories for glass mounting of the ASPIRMURO MATIC serie.
• ASPIRTIMER:
Accessory for timerization of the ASPIRMURO and ASPlRMURO MATlC series also for glass-mounted models.
3.

CLEAnInG AnD MAInTEnAnCE

After having disconnected the power supply, using the greatest care, wash every dirty part in water with neutral washing liquid.
ATTEnzIOnE:
nEVER IMMERSE ELECTRICAL PARTS In WATER OR OThER LIqUIDS.
4. OPERATInG InSTRUCTIOnS FOR MODELS WITh TIMER
WARnInG: Always choose a safe location for the heater, keeping in mind the safety instruction outlined in point 1.
On the models with ASPIRTIMER the operating time is originally set for about 45 seconds.
normal operation is ensured also with no bulb or with a burnt out bulb.
The ASPIRTIMER switches on the fan when the light is turned on.
When the light is turned off, the fan continues to operate, for the programmable time, from 45 sec. to 30 min.
To prolong the operation time, proceed as follows:
• Disconnect the power supply.
• Turn the trimmer (6) on the ASPIRTIMER carefully with a screw-driver in the direction of the arrow (Fig. 4).
• Verify if the operational time has been correctly set, if not repeat following the instructions carefully.
• The installation and the electrical connection are illustrated on Fig. 4.
5. MODELS WITh PULL-CORD
The electrical connection is illustrated on Fig. 3. It is only necessary to exclude the one-pole switch (A) as described on the electrical scheme.
6. DISPOSAL
WARnInG:
Important information concerning the environment friendly disposal of the appliance
This product conforms to EU Directive 2002/96/EC. The symbol of the barred waste bin indicates that, at the end of its useful
life, the product has to be collected separately from the domestic waste.
The user will have to take the product to a collection centre for waste electrical and electronic equipment, or return it to a
retailer on purchase of a replacement. Failure to do so may incur the penalties established by laws governing waste disposal.
Proper differential collection and the subsequent recycling, processing and environmentally compatible disposal of waste
equipments avoids unnecessary damage to the environment and possible related health risk and promotes also recycling of
the materials used in the appliance.
