General Description; Technical Speci Cations; Name Of The Main Components - Moretti Easyred SL2040 Betriebs Und Installationsanleitung

14

Technical speci cations

WIDTH
HEIGHT (CHAIR OPEN)
HEIGHT (CHAIR CLOSED)
WEIGHT
MAXIMUM LOAD
WARNING! Do not exceed the speci ed
workload; this can cause damage to
the patient and/or to the chair.

Name of the main components

1 10
6
9

GENERAL DESCRIPTION

1) Rear transport levers
2) Handles for transportation on wheels
56 cm
3) Belts for immobilisation of the patient
4) Arm-rest
95 cm 5) Main frame
6) Unlocking pawls
7) Front transport levers
97 cm
8) Wheels
9) Inclination hub
10 kg
10) Nylon seat/back
11) Seat handle
170 kg
2
8
OPERATION
3
7
4 5 3
11
6
