ASPIMED 3.3 is a surgical aspirator working with 230V ~ / 50 Hz network electricity, to be used for the aspiration
of the body liquids (such as, for example mucus, catarrh or blood). The device is equipped with 4 antistaticwheels,
two with brakes, and movement handle. Easily movable and designed for virtually continuos use.
Thanks to this characteristics and to the rating that it has, this product is particularly suitable for hospital use, on the
tracheotomized patients and surgical applications.
Made of highly heat resistant, electrically insulated plastic material in conformity with the latest European safety
standard, the product is supplied with two polycarbonate autocavable jars with overflow valve and equipped with
aspiration regulator and vacuum indicator located on the front panel.
Available under request with differents versions for applications and use (version with remote control, version with
4 litre jars, version with flow direction regulator).

GENERAL WARNING

READ INSTRUCTION MANUAL CAREFULLY BEFORE USE
ONLY HIGHLY QUALIFIED STAFF USE RESERVED
THE INSTRUMENT MUST NOT BE DISASSEMBLED
FOR A TECHNICAL SERVICE ALWAYS CONTACT MORETTI

IMPORTANT SAFETY RULES

1.
When opening packing verifies the device state: always check the presence of damages on the plastic surface,
this can expose under tension internal parts. Also check the main cable integrity.
In case of damage do not connect the plug to the socket. Check integrity before every use.
2.
Before connecting the instrument, always check that the electrical requirements on manufacturer label and the
plug used comply with the electrical network used.
3.
Keep special attention to:
Use only original accessories;
The device can be used only with the bacteriological filter;
Place instrument on stable and flat surfaces and to hevitate the blockage of the air inlets on sides;
Do not use in presence of air inflammable anaesthetic, oxygen or nitrous oxide;
Do not touch the instrument with we hands, and avoid contact with liquids;
Keep off the reach of children or not capable people without supervision;
If not used do not leave the instrument connected to network;
Do not pull cable to remove plug from socket; disconnect hold plug with fingers;
Use and keep the instrument in a safe environment, protected from bad weather condition and keep off
excessive heating;
4.
The device must be used for the use it was designed for: surgical aspirator. A different use must be
considered improper and dangerous. Manufacture cannot be considered responsible for damages due to improper
use or connection to an electrical system not complying with current regulations.
Do not use for naything else but the use defined by manufacturer;
5.
Instrument and accessories discharging must be done following current law regulations in every country of use.
10

TECHNISCHE DATEN

Modell
Gerätetyp
Klassifizierung UNI EN ISO 10079-1
Spannungsversorgung
Leistungsaufnahme
Sicherung
Max. Saugdruck
(nie flaschen)
Max. Saugleistung
(nie flaschen)
Gewicht
Abmessungen
Betriebsart
Betriebsbedingungen
Lagerhaltungsbedingungen
SYMBOLE
~
Hz
I
0
II
ASPIMED 3.3
Medizinprodukt Klasse II a
HOHES VAKUUM / HOHES FLOW
230 V ~ / 50 Hz
160 VA
F 1 x 4 A 250V
- 0.90 bar
60 l /min
13 kg
600 x 460 x 420 mm
Dauerbetrieb
5 ÷ 35° C
Raumtemperatur
30 ÷ 75 % RF
Raumfeuchtigkeit
0 ÷ 2000m N.N.
Höhe:
- 40 ÷ 70° C
Raumtemperatur
10 ÷ 100 % RF
Raumfeuchtigkeit
Gerät der Isolierstoffklasse 2
CE-Kennzeichnung gemäß Richtlinie 93/42/EWG
Mit: CA-MI snc Via Ugo La Malfa n°31
43010 Pilastro (PR) Italia
Achtung, im Handbuch nachlesen
Gerät Typ B
Sicherung
Kühl und trocken lagern
Lagerhaltungstemperatur - 40 ÷ 70° C
Wechselstrom
Netzfrequenz
Ein
Aus
Fernbedienung
