Pico transmitter
Switching ON / OFF
Pico is switched ON/OFF using a magnet switch which is attached at the back of the
transmitter. To switch the transmitter on, remove the magnet switch. The green LED
will illuminate. The transmitter is switched off when the magnet switch is placed at its
spot.
Charging the battery
1.
For first time use, charge the device overnight to full. This will help the battery to
gain its maximum capacity and lifecycle.
2.
Plug the battery charger into the connector.
3.
If you see the red LED illuminates, it means the device is charging. Single battery
Pico take take up 4 hours for full charge, charging time may be doubled for dual
battery Pico.
4.
When the battery is fully charged, the green LED will illuminate.
LED indicator
Constantly green - The device is fully charged.
Constantly red - The device is being charged.
Blinks green every second . The device is switched on and generating signal.
Blinking green and red simultaneously - The device is switching the channel.
Switching channel
1.
Make sure the device is switched off.
2.
Quickly
remove the magnet switch and place the magnet switch on the CH sign
3.
You will notice the red and green LED blinking at the same time, this means the
device is switching between channels.
4.
The channel is rotated after several pulses. Use a
receiver with matching frequency to check the
correct channel.
Note: Not available in all models.
ON
Magnet switch
Copyright © 2008 Tracker Oy. All rights reserved.
EN
OFF
CH
