INSTALLATION
Before installing the intercom panel in its permanent location, we recommend that you carry
out a test on the fl ying leads. If the intercom connects to your WiFi network, you can continue
with permanent installation. Otherwise, a wired installation will be recommended (refer to the
instructions)
1 - Screw the shield into the wall using the screws provided.
2 - Connect the power cable to the back of the intercom panel (the red wire
in V+ and the black wire in V-), insert a microSDcard (not included) if you wish
to make recordings, then connect to the mains supply.
3 - Insert the intercom panel into the shield and fasten it using the anti-theft
screws provided.
APPLICATION

LIVE VIEW

GB2
SNAPSHOT
CFI EXTEL VisioSmart - 04/2017
Tap to capture screen images
Tap to turn on/off the volume in Live View mode
Tap to record video in device memory card
Automatic gate opening mechanism
Electric strike plate opening mechanism
To hang up again
Stand by video
Tap to dialogue
