Terminal
1.2
1.6
1.1, 1.5
2.1, 2.5
3.1, 3.5
4.1, 4.5
1.4, 1.8
2.4, 2.8
3.4, 3.8
4.4, 4.8
The switching channels have potential-free relay con-
tacts.
For power supply and supply of external
conductor connections of the switching
channels, only the same phase may be used
for the device.
A total connection load of 25 A may not be
exceeded. Therefore, the supplying phase can
be protected with different fuses.
Function
Power supply (phase conductor)
Power supply (neutral conductor)
Phase conductor connection, channel 1
Switched phase channel 1
Phase conductor connection, channel 2
Switched phase channel 2
Phase conductor connection, channel 3
Switched phase channel 3
Phase conductor connection, channel 4
Switched phase channel 4
Installation
