11.68 mm
(0.46 in.)
11.68 mm
(0.46 in.)
11.68 mm
(0.46 in.)
11.68 mm
(0.46 in.)
66.70 mm
(2.62 in.)
(Actual Size)
MOUNTING FLANGE
BRIDE DE MONTAGE
BEFESTIGUNGSFLANSCH
BRIDA DE MONTAJE
FLANGIA DI MONTAGGIO
428.74 mm
(16.88 in.)
330.70 mm
(13.02 in.)
MX412
571.44 mm
(22.50 in.)
473.40 mm
(18.64 in.)
MX418
468.11 mm
(18.43 in.)
333.87 mm
(13.14 in)
MX412S
607.64 mm
(23.92 in.)
473.40 mm
(18.64 in)
MX418S
14.40 mm
(0.56 in.)
DIMENSIONS
DIMENSIONS
ABMESSUNGEN
DIMENSIONES
DIMENSIONI
FIGURE 6
ABBILDUNG 6
10
98.04 mm
(3.86 in.)
98.04 mm
(3.86 in.)
134.24 mm
(5.28 in.)
134.24 mm
(5.28 in.)
50.80 mm
(2.00 in.)
14.40 mm
(0.56 in.)
38 mm
(1.5 in.)
SHOCK MOUNT ASSEMBLY
ASSEMBLAGE DE LA MONTURE SILENT–BLOC
SCHWINGDÄMPFER–BAUGRUPPE
SOPORTE AMORTIGUADO
SUPPORTO ANTIVIBRAZIONE
FIGURA 6
20.07 mm
(0.79 in.)
20.07 mm
(0.79 in.)
20.07 mm
(0.79 in.)
20.07 mm
(0.79 in.)
43.18 mm
(1.70 in.)
