Bedienungsanletung | Users manual
Schritt 2:
1
No. Description
1
back ground link tube
4
chin up bar
5
short up link tube left
6
short up link tube right
7
reinforcing plate
8
hexagon bolt
9
washer
10 lock nut
11 hexagon bolt
12 washer
13 lock nut
28 back up link tube
34 hexagon bolt
46 hexagon bolt
60 hexagon bolt
85 back pulley frame
86 back short ground link tube
87 spring washer
11
2
1
Note
Qty.
1
1
1
1
t3.0x59x140
2
M10x100
4
Φ10
16
M10
6
M12x75
4
Φ12
10
M12
4
1
M10x20
4
M10x50
2
M12x30
2
1
1
Φ12
2
3
