Schritt 9
71
54
57
9
2
53
No. Description
9
washer
10 lock nut
53 hexagon bolt
54 sliding sleeve left
55 sliding sleeve right
56 guide rod
57 T shape locking spring pin
71 hexagon bolt
10
Note
Φ10
M10
M10x70
Φ10
M10x75
53
Qty.
12
6
4
1
1
2
2
2
9
10
71
56
55
