2.0 Layout – Scope of delivery
GB
Pos. Name
Covering foil
Thermal insulation shells
Plate heat exchanger
Screw union with integrated gravity brake
Thermostatic head with stainless steel spiral probe
Angled control valve kvs= .
Flow switch
Circulation pump
Base plate
KW Cold water
WW Hot water
HVL Heating flow
HRL Heating return
Matching accessories:
x ball valve (Flow and return) OEG No.
x ball valve (WW) OEG No.
The cold-water connection has to be fitted with the required safety fittings as per DIN
.
HVL
WW
HRL
SecuFresh Fresh water station
