Surgical sequence
Surgical sequence
SinCrest Ø 3.0 for > _ Ø 3.75 implant surgical sequence
Locator Probe
Drill Drill
Ø 1.2
Drill Stop
L 7
SinCrest Ø 4.0 for >_ Ø 4.8 implant surgical sequence
Locator Probe
Drill Drill
Ø 1.2
Drill Stop
L 7
2
2
≥
RX Guide
PIN Drill
Ø 1.2 Ø 3.0
≥
RX Guide SinCrest
PIN Drill
Ø 1.2 Ø 3.0
Ø 3.0
Drill Stop
SinCrest SinCrest
Drill Drill HB
Ø 3.0 Ø 3.2
IN CASE OF
HARD BONE
Drill Stop
L 7
SinCrest
Drill Drill
Ø 4.0
L 7
SinCrest
Ø 3
SinCrest SinCrest
Drill HB Ø 4
Ø 4.2
IN CASE OF
HARD BONE
