4. Operating Instructions

See Die and Accessory Compatibilty Table on page 15
Extended Sliding Tray
Using any size AllStar
Originals Dies without Crease Rule
1. Place a die onto an appropriately sized Cutting Pad. Place paper or desired
material to be cut on top of the die. Place another appropriately sized Cutting
Pad on top of the paper or material to create a "sandwich" (Figure B).
2. Place sandwich on top of the Adapter Pad in the Sliding Tray.
3. Push Sliding Tray into the opening of the Big Shot Pro Machine. Keep hands
away from roller and dies while in use.
WARNING
4. Note the rotation of the Crank Handle and continue to rotate it in the same
direction until the sandwich has passed through the opening of the rollers.
Dies can be passed through the rollers in either direction, from the right or
from the left.
5. Remove the sandwich from the Big Shot Pro. Your die-cut shapes are ready
to use!
*A Crease-Rule Die is similar to a regular Bigz (steel-rule) Die; however, it contains
both cutting (sharp) rule and crease (blunt) rule.
"Sandwich"
Figure B
® Dies or Sizzix Bigz, On the Edge
Pinch and cutting hazard. Keep hands, fingers
and clothing away from contact with rollers
and dies while in use.
6
Extended Cutting Pad
Fabric
Bigz Die
Extended Cutting Pad
Extended Adapter Pad
™ or
