– Install the passthrough with P8-P9 plugs into the 8-pin plug in the
Infinitiv power supply unit.
7. Unscrew the bolt in the A1200 board to the right of the CPU expansion
slot and replace it with a hexagon spacing sleeve.
8. Install the passthrough for the CPU slot into the processor connector.
9. If you have the ELBOX Fast ATA 1200 (Power Flyer) controller
installed, connect the ribbons to the controller.
10. Set jumpers in the MEDIATOR PCI busboard based on your
configuration (Refer to the chapter 2.2. HOW TO SET JUMPERS IN
MEDIATOR PCI 1200 for detailed instructions).
11. Install the MEDIATOR PCI 1200 board in the connector in the
passthrough for the CPU slot.
12. Fix the MEDIATOR PCI 1200 board with the M3 bolt to the spacing
sleeve.
13. Connect the PSU's P8 and P9 plugs in the proper power supply
connection points in the MEDIATOR PCI 1200 board.
14. Insert cards into PCI slots:
Remove the screw and coverplate from the unused expansion slot.
–
– Insert the PCI card firmly into the slot.
Secure the PCI card by fastening its bracket with the removed
–
screw firmly into the computer chassis.
15. Re-assemble the Amiga case (Refer to your E/BOX or Infinitiv user's
manual for detailed instructions).

4. Software Installation

4.1. Installing the Driver

Installing your hardware is not enough for running PCI cards in the
MEDIATOR PCI 1200 in your Amiga 1200. The following procedures are
simple steps for installing your MEDIATOR PCI software drivers.
4.2. Installing the MEDIATOR PCI 1200 Driver
Note: The Installer program (from INSTALL Workbench) must be present in
the C: drawer of the booting disk.
1. Boot the computer from its hard disk.
2. Insert the MEDIATOR_PCI_1200 floppy disk into the floppy disk drive.
3. Run MEDIATOR_Install from the MEDIATOR_PCI_1200 floppy disk.
