If you are indeed an experienced user in the field, you might as well need
this section to guide you only for more detailed explanation about specific
steps in the installation process.

3.2. Before You Begin

Step 1. Please make sure that your computer system meets the minimum
requirements and that the Mediator PCI 1200 package contents is
complete (Refer to System Requirements and Package Contents
in Chapter 1).
Step 2. After confirming that your system meets all the requirements,
prepare the necessary tools. You should have an appropriate
screwdriver(s) and a container for the screws removed from the
system.
Note: For Infinitiv tower case with Infinitiv Power Supply (with one 8-pin
plug), you must have an adapter for standard connectors in the
PC AT power supply unit with P8 - P9 plugs or you must replace
the Infinitiv power supply with any standard PC AT power supply.
3.3. Installing Your MEDIATOR PCI 1200
Now you are ready to install the MEDIATOR PCI 1200 busboard and
connect the related devices.
1. Power off your Amiga.
2. Turn off any external devices that are attached (printer, monitor, etc.).
3. Disconnect all the cables and connectors from your computer.
4. Remove the Amiga's tower casing (Refer to your E/BOX or Infinitiv user
manual for detailed instructions).
5. Remove the turbo card (memory expansion) from the processor's
connector.
6a. For E/BOX cases:
– Disconnect the power supply unit's P8 and P9 plugs from the PSU
adapter.
– Remove the PSU adapter from the computer (no longer needed).
6b. For Infinitiv tower cases with Infinitiv Power Supply units (8-pin plugs):
– Disconnect the Infinitiv's PSU 8-pin plug from the PSU connector.
