2.2. How to set Jumpers in MEDIATOR PCI 1200
MEMORY WINDOW
Set 0 MB If you use 8MB of RAM installed in the memory expansion or in
the turbo card configuring this memory in the lower boundary
(e.g. M-TEC 1230 turbo card).
Set 4 MB If you use 4MB of RAM installed in the memory expansion or in
the turbo card configuring this memory in the lower boundary
(e.g. M-TEC 1230 turbo card) or if you use the 4 MB PCMCIA
memory expansion.
Set 8 MB If you use 8 MB or more RAM installed in the turbo card
configuring this memory in the higher boundary (all the turbo
cards for which more than 8MB Fast RAM may be installed
e.g. Apollo 1230, Apollo 1240, Apollo 1260, Blizzard 1230,
Blizzard 1240, Blizzard 1260, Blizzard PPC, Elbox 1230-II).
CONFIG Set CLOSED
Set OPEN
WAIT OPEN
CLOSED

3. Hardware Installation

3.1. Hardware Installation Instructions
This section is intended as a guide for those who are not familiar with the
installation of Amiga peripherals and software applications and as a
reference for experienced users. Follow the step-by-step instructions and
illustrations in this section to pass through the installation process if you are
new to installing Amiga peripherals and software applications.
If you use A1200 with the memory
expansion, M-Tec 1230, Elbox 1230, GVP
1230, Apollo 1230, Apollo 1240, Apollo
1260, old Blizzard cards.
If you use A1200 with the empty expansion
slot, Blizzard 1230-IV,
Blizzard 1260, Blizzard PPC.
For all known turbo/memory expansion
cards (default setting).
Currently not used.

Blizzard 1240,
