64 MB or more SDRAM installed on the SharkPPC G3/G4 turbo board
•
Hard disk drive

1.3. Package Contents

Please check that your Mediator PCI 1200 package contains the following
items:
•
Mediator PCI 1200 busboard
•
Passthrough for the CPU expansion slot
•
Spacing sleeve and M3 bolt
•
Floppy disc with software
•
This User's Manual
All Mediator PCI 1200 packages have been checked for completeness and
functionality before shipment.
2. Jumpers Description
2.1. MEDIATOR PCI 1200 Jumpers Description
MEMORY WINDOW
0 MB PCI memory space unavailable, access only to PCI I/O space;
allows using PCI Ethernet, sound, modem etc. cards; use of
graphic cards disabled.
4 MB 4 GB PCI memory space available through the 4 MB Amiga
memory window, access to PCI I/O space and to PCI Memory
Space through the 4 MB window; allows using any PCI cards.
8 MB 4 GB PCI memory space available through the 8 MB Amiga
memory window; access to PCI I/O space and to PCI Memory
Space through the 8 MB window; allows using any PCI cards.
CONFIG Type of configuration cycles during Amiga's start-up.
WAIT Adding waitstates during write cycle in Amiga.
