Model assembly
2. With the servo centered, install and adjust the pushrod and
clevises. Connect the clevis to the outermost hole on the control
horn.
Main wing installation
1. Connect the ailerons servo wires to their respective ports then
attach the wing onto the fuselage.
2. Secure the wing onto the fuselage with the quick release bolts.
3. Connect the wing struts to the fuselage- Slide the root of the
strut into its slot then push aft to lock.
