Ingersoll-Rand No. 50
Always use an air line lubricator with these tools.
We recommend the following Filter-Regulator-Lubrica-
tor (FRL) Unit:
Model Handle Drive
I.D. Type in
244A 1/2 sq.
1/2 sq.
pistol
with
244A-2
extended
anvil
Tested in accordance with PNEUROP PN8NTC1.2
■
♦ Tested in accordance with ISO8662-7
•
Tested in accordance with ISO3744
SAVE THESE INSTRUCTIONS. DO NOT DESTROY.
When the life of the tool has expired, it is recommended that the tool be disassembled,
degreased and the parts be separaed by material so that they can be recycle.
LUBRICATION
Ingersoll-Rand No. 100

INSTALLATION

Main Line(s) Inner Ø
to be 3X Size of
Air Tool's Inlet Ø
To Air
System
To Air
Tool
Emergency L
Shut-Off
Valve
Lubricator Regulator
Drain Regularly

SPECIFICATIONS

Recommended
Impacts Torque Range
bpm ft•lb (N•m)
(40-350)
1,300
(54-474)
Inside USA use FRL unit #C28-04-FKG0-28
Outside USA use FRL unit #C28-C4-FKG0
After each forty-eight hours of operation, or as experi-
ence indicates, inject about 4 cc of the recommended
grease into the Grease Fitting (3).
Branch Line(s) Inner Ø
to be 2X Size of
Air Tool's Inlet Ø
R
F
Filter
FRL
Compressor
(Dwg. TPD905-2)
■ Sound Level
dB (A)
• Power
Pressure
96 109
3
Inlet
♦ Vibrations
Connection
Level (Thread)
2
m/s NPT
5.5 1/4
Minimum
Inside Ø (Air
Hose)
in (mm)
3/8 (10)
