Color LaserJet Pro M454
Getting Started Guide
NOTE: An internet connection is required to set up the printer and download the software driver.
FAQ
For frequently asked questions, go to
or scan the QR code.
IMPORTANT:
Follow Steps 1 - 2 on the
printer hardware setup
poster, then continue
with Step 3.
4. Download and install the software
NOTE: Do not connect the USB cable until you are prompted to do so.
Method 1: Download HP Easy Start (Windows and macOS)
HP Easy Start will detect the printer, assist with selecting the printer connection
type (USB, Wired, or Wireless), and install the software.
1. From the computer, go to 123.hp.com/laserjet, and click Download.
2. Run HP Easy Start.
3. When prompted to select a connection type, select the appropriate option for the
type of connection.
NOTE: If HP Easy Start does not detect the printer or the software does not install
automatically, go to Method 2: Manually download from printer support website
(Windows).
Troubleshooting Tips
The installation software might not detect the printer during wireless setup. Follow the steps below to connect the printer to the same wireless network as the computer.
Non-Touchscreen control panels
1. From your printer, disconnect the Ethernet cable if attached.
2. Reset Printer Network Settings from Printer Control Panel:
OK > Setup > Network setup > Restore Network Setting.
The Wireless light begins blinking.
3. Install the software using Method 1 or Method 2 above.
www.hp.com/support/colorljm454
www.hp.com/support/colorljM454FAQ
3. Set up the control panel
After turning on the printer, wait for it to initialize. To navigate the non-touchscreen control panel,
use the arrow buttons and the OK button. To navigate the touchscreen control panel, use touch,
swipe, and scroll gestures. Follow the prompts on the control panel to configure Language,
Country/Region, and Self-managed or IT-managed.
• Self-managed: Optimized default settings for most users that include guided setup and
configuration steps and automatic updates.
• IT-managed: Optimized default settings for fleet manageability.
Follow additional prompts to complete control panel setup.
Settings are fully customizable after initial setup.
Connect the printer to a wireless network (wireless models only)
www.register.hp.com
Method 2: Manually download from printer support website
(Windows)
1. From the computer, go to www.hp.com/support/colorljm454.
2. Select Software and drivers.
3. Download the software for your printer model and operating system.
4. Launch the software file from the folder where the file was saved.
5. Follow the onscreen instructions to install the software.
6. When prompted to select a connection type, select the appropriate option for the
type of connection.
Manually configure the IP address
See the printer user guide for information on how to manually configure the
IP address at www.hp.com/support/colorljm454.
Touchscreen control panels
1. From the Home screen on the printer control panel, swipe the tab at the top of the
screen downward to open the Dashboard, and then touch the Wireless
2. Touch the Setup icon.
3. Touch Wireless Settings.
4. Touch Wireless Setup Wizard.
5. Follow the display instructions to complete the setup.
6. Install the software using Method 1 or Method 2 above.
2
English................. 1
Français ............... 3
Deutsch ............... 5
Italiano ................ 7
Español ............... 9
Català ................ 11
Dansk ................ 13
Nederlands ........ 15
Eesti................... 17
Suomi ................ 19
Latviešu ............. 21
Lietuvių ............. 23
Norsk ................. 25
Português ......... 27
Svenska ............. 29
icon.
