Operation

Display
The values will be shown with three digits, and after an opera-
tion the controller will return to its standard mode and show the
measured discharge temperature.
Light-emitting diodes (LED) on front panel
There are LED's on the front panel which will light up when the
belonging function is activated.
The upper LED will indicate the valve's opening degree. A short
pulse indicates a slow liquid flow and a long pulse a fast liquid
flow.
The three lowermost LED's will flash, if there is an error in the regu-
lation.
In this situation you can upload the error code on the display and
cancel the alarm by giving the uppermost button a brief push.
The buttons
When you want to change a setting, the two buttons will give you
a higher or lower value depending on the button you are push-
ing. But before you change the value, you must have access to the
menu. You obtain this by pushing the upper button for a couple
of seconds - you will then enter the column with parameter codes.
Find the parameter code you want to change and push the two
buttons simultaneously. When you have changed the value, save
the new value by once more pushing the two buttons simultane-
ously.
Gives access to the menu (or cuts out an alarm)
Gives access to changes
Saves a change
Examples of operations
Set reference
1. Push the two buttons simultaneously
2. Push one of the buttons and select the new value
3. Push both buttons again to conclude the setting
Set one of the other menus
1. Push the upper button until a parameter is shown
2. Push one of the buttons and find the parameter you want to
change
3. Push both buttons simultaneously until the parameter value is
shown
4. Push one of the buttons and select the new value
5. Push both buttons again to conclude the setting
Factory setting
If you need to return to the factory-set values, it can be done in this way:
- Cut out the supply voltage to the controller
- Keep both buttons depressed at the same time as you reconnect the supply voltage
EKC 319A
English
Instructions RI8HY252 © Danfoss 09/2005
Menu survey
Function
Normal display
Read the measured discharge gas temperature
If you wish to see the actual opening degree,
give the lower button a brief push
If you wish to set the temperature reference
you obtain access by pushing both buttons
simultaneously
Display / Control
Select unit (0=°C, 1=°F)
Start / stop of regulation
Alarm
Alarm limit
Time delay for alarm
Function of the alarm relay when the tempera-
ture exceed the alarm limit
0: Alarm relay active
1: Alarm relay not active
Regulating parameters
Proportionale factor Kp
I: Integration time Tn
Periode time
Miscellaneous
Controller's address
ON/OFF switch (service-pin message)
Set supply voltage frequency
Select the showing of the "normal display":
0: Discharge gas temperature is shown
1: Valve's opening degree is shown
Manual control of outputs:
OFF: No manual control
1: Valve output put in pos. ON
2: Alarm relay activated (cut out)
Service
Read discharge gas temperature
Read temperature reference
Read status of input DI
Read valve's opening degree
*) This setting will only be possible if a data communication module has been
installed in the controller.
Error messages
The controller can give the following messages:
E1
E17 Error message
E18
A3 Alarm message
Literature survey:
Manual for EKC 319A ............................................................................................... RS8EB---
Instructions for EKC 319A ...................................................................................... RI8HY---
Installation guide, "Data communication link for ADAP-KOOL
SW = 1.1x
Para- Min. Max.
meter
-
-
- -70°C 160°C
r05 0 1
r12 OFF ON/on
A16 -50°C 150°C
A17 0 s 999 s
A19 0 1
n04 0,5 30
600 s /
n05 60 s
Off
n13 3 s 10 s
o03* 0 119
o04* OFF ON
0/50 1/60
o12
Hz Hz
o17 0 1
o18 OFF 2
u01
u02
u10
u24
Errors in the controller
The temperature sensor is disconnected
The temperature sensor is shortcircuited
Alarm temperature limit is reached
" ........... RC8AC---
®
Fac.
setting
°C
%
125
0
on
135
0
1
15
120
3
-
-
50
0
off
°C
°C
%
5
