SimPad PLUS / Link Box PLUS - Regulatory Information
Link Box PLUS Connections
DC input
Ethernet
Future
Manikin
Battery #1
Blood Pressure
USB
Audio in
Audio out
Battery #2
Li-Ion Battery
Battery type
Cell type
Voltage
Capacity
Size
Weight
Battery Charging
Charging voltage input
Charging method
Constant current
Expected cycle life
Charging time:
Charging Indicator
** This product is intended to be supplied by a Listed Power Adapter or DC power source, rated
12Vdc, 3.33A minimum, Tma = 35 degree C, and the altitude of operation = 5000m. Contact
Laerdal for further assistance with purchasing the power source.
12V DC, 3.33 A minimum. (for power adapter**),
or 7.2V DC, 4.4A (for battery)
RJ45 connector
Connector for future use
Power and signals to manikin. Pulse, sounds etc
Connector for Laerdal Li-Ion Battery
Cuff pressure input: 0 - 300 mm Hg
USB A input / output
3.5 mm jack with TRS input. Line in or microphone level
3.5 mm jack with TRS output. Line out level
Connector for Laerdal Li-Ion Battery
Li-Ion, 4 cells
LIC 18650-22PC
7.2 V nominal
4.4 Ah typical (32 Wh)
98 x 78 x 28.1 mm (3.86" x 3.07" x 1.11")
270 g (0.6 Ib) approximately
9 - 15V DC, 1.6 A max
Constant Current + Constant Voltage
1.33A typ.
700 cycles for ≥ 1400mAh (cell)
0 - 80%: 30% per hour. 80% - 100%: 1 hour
1. The charging indicator is only active when there is a charging voltage present
2. Charging: Steady yellow light
3. Charged: Steady green light
