Application informations
The conformity certificate
confirms that the
instruments meet
8 8 9 9 / / 3 3 3 3 6 6 / / E E E E C C guidelines.
Protective casing
Immersion depth for measurement
≥ 20 cm
Logger penetration probe
Please r r ead p p rior t t o i i nitial o o peration
- Risk of injury from measuring tip
- Observe sensor measurement ranges
- Do not exceed storage and operating temperature
- Protect instrument from direct sunlight
Inexpert h h andling w w ill c c ancel y y our w w arranty c c laims.
Initial o o peration
- Screw in handles.
- Unscrew protective casing.
- Remove data logger and program prior to operation
(refer to instruction manual for testo 1 1 75).
- Reattach data logger to penetration probe. Observe
position!
Note:
The data logger is also weather-resistant without the
PP protective casing.
Technical d d ata o o f a a ttachable l l ogger w w ith p p robe
Parameters:
°C / °F
Measurement range:
-40 to +120 °C
Sensor:
NTC sensor external
Resolution:
0.1 °C
Accuracy:
± 0.5 °C (-25 to +70 °C)
± 1.2 % of mv (rem. range)
Channels:
1 channel (external)
Memory capacity:
16000 readings; Continuous
measuring can be programmed
Logger dimensions:
82 x 52 x 30 mm
Logger housing:
ABS / TPE
Probe pipe:
Length: 1500 mm / Ø 12 mm
Ø probe tip:
6 mm
Battery life:
Typical: 2½ years
(Meas. cycle: 15 min., oper.
temperature: -10 to +50°C,
Display: On,
Status display (green LED): Off)
Storage temperature: -40 to +70 °C
Warranty:
2 years
0628 0134
en
You have three options for reading data from the data
logger:
1. Via the testo ComSoft software. The data is sent
directly to a PC.
Please read the Instruction manual on testo
ComSoft software.
2. Via the testo 5 5 80 data collector
Option 1 1 : M M easurement f f inished
Unscrew protective casing. Carefully remove data
logger and place in readout holder. The data is
then read out using the testo Comsoft software.
Option 2 2 : D D uring m m easurement
Remove handles. Unscrew protective casing
Push bottom casing downward . Attach
readout holder to data logger . Then read out
data via testo Comsoft software.
For more information, please read the Instruction
manual for the testo 5 5 80 instrument.
3. Printout via the fast testo 5 5 75 printer
For more information, please read the Instruction
manual for the testo 5 5 75 measuring instrument.
.
