Prevent property damage!
• Avoid water, oil, potholes and very rough
surfaces .

Assembly

The product is supplied folded for transport .
Proceed as follows to set it up for use:
Unfolding (Fig. A)
1 . Pull the clamping lever (2) up and hold in
place .
2 . Pull the lever (1) up, then release the clamping
lever (2) and unfold the steering post (3) until
it locks into place .
Handle assembly (Fig. B)
1 . Remove the handles (4) from the holders (5) .
2 . Lift the cover flap (6) .
3 . Push in the locking buttons (7) on the handles
and slide the handles into both ends of the
T-bar (8) on the steering post . You must hear
the locking buttons lock into the designated
holes (9) .
4 . Push the cover flap over the locking buttons .
Adjusting the steering post (Fig. C)
The steering post can be adjusted to four differ-
ent levels . Only use the product with the locking
button locked into one of the four designated
holes and after securing the steering post with
the quick-release connector!
1 . Release the quick-release connector (10) on
the steering post .
2 . Pull up on the steering post (11) until the
locking button (12) latches into one of the four
holes (13) .
3 . Secure the steering post by locking the
quick-release connector .
Note: If the quick release is not tight against the
bar when closed, tighten the knurled screw using
the included socket head wrench .
Verify the quick release is locked before tight-
ening .
Steering head bearing (Fig. D)
On product delivery the steering head bearing
is preset . If the handlebar has too much play
after some time or becomes too tight, have the
steering head bearing adjusted by a speciality
retailer or a bicycle shop .
Brake

Adjusting the brake

ATTENTION!
The brake must be adjusted so the
back wheel moves freely when the
brake lever is released and locks when
engaging the brake lever.
Turn the adjusting and locking nut (21) to the left
to reduce the braking force, turn the adjusting
and locking nut to the right to increase the brak-
ing force (Fig . E) .
Readying the product
for transport
1 . Release the quick-release lever (10) on
the steering post and push in the locking
button (12) (Fig . C) .
2 . Push the steering post (11) in all the way and
tighten the quick-release lever (10) (Fig . C) .
3 . Lift the cover flap (6) (Fig . B) .
4 . Push in the locking buttons (7) on the handles
and pull the handles (4) out of the T-bar (8)
(Fig . B) .
5 . Secure the handles in the holders (5) (Fig . B) .
6 . Pull the clamping lever (2) up and hold
in place (Fig . F) . Pull the lever (1) up, then
release the clamping lever (2) .
7 . Move the steering post toward the deck until it
locks into place (Fig . F) .

Use

Riding, braking, parking (Fig. G)
• Place one leg on the deck (14) and put into
motion by evenly pushing off with the oth-
er leg .
• To brake, step on the brake plate (15) or pull
the brake lever (Fig . E) .
• Swing out the stand (16) to park .
Only park the scooter on level surfaces .
GB/IE 11
