Hama HD-10 Bedienungsanleitung Seite 4

• Connect the included 2-in-1 cable to the USB port on the power pack (OUT 5V/2.1A) and to the
Micro-USB or USB-C port on your terminal device (mobile phone, smartphone, etc.).
• The Micro-USB charging/connecting cable included may not be suitable for the USB connection on
your terminal device. In this case, use the USB cable that was included with your terminal device.
• When using the USB-C output (OUT 5V/3A) for charging, please connect a suitable USB-C
charging cable to the power pack's USB-C output and to the port of your terminal device.
• Charging begins automatically. The status LEDs show the remaining capacity when the Power Pack
is charging.
• The current battery status of your terminal device will appear on this device.
• Press the button on the power pack twice to stop charging and switch it off. The status LEDs
should switch off.
• The Power Pack will automatically switch off if it is not connected to a terminal device.
Note – Optimised charging
Optimised charging means that the Power Pack recognises the connected terminal device and
supplies it with the optimal current to minimise charging time. Please note that the maximum
power output of the power pack is 3000 mA.
5. Care and Maintenance
Only clean this product with a slightly damp, lint-free cloth and do not use aggressive cleaning
agents.
6. Warranty Disclaimer
Hama GmbH & Co KG assumes no liability and provides no warranty for damage resulting from
improper installation/mounting, improper use of the product or from failure to observe the operating
instructions and/or safety notes.
7. Technical Data
USB-C input
USB-A output
USB-C output
Output total
Battery type
Min. capacity
Typ. capacity
4
5 V 3 A
5 V 2.1 A
5 V 3 A
5 V 3 A (max.)
3.7 V / Li-Po (High Density)
10000 mAh / 37 Wh
10100 mAh / 37.37 Wh
