Defined Error messages:

Code Explanation
E103 Voltages out of range
E400 FW download error
2
E401 E PROM error
2
E402 E PROM Data corrupted
E403 Sensor Data read error
E404 HW initialization error
E405 HW recognizing error
E406 HW test error
E407 EEPROM read error
E408 Memory test error
E409
Action
Fatal. Clicking OK, the message
disappears and the IME is not ready.
Check GXPicture version (must be
2.04b or higher).
Fatal. Clicking OK, the message
disappears and the Active_X
continues with new retries.
Change USB port, change PC. If it
persists, unit KO.
Fatal. Clicking OK, the message
disappears and the IME is not ready.
Change USB port, change PC. If it
persists, unit KO.
Fatal. On OK, the message disappears
and the IME is not ready.
Change USB port, change PC. If it
persists, unit KO.
Fatal. Clicking OK, the message
disappears and the IME is not ready.
Change USB port, change PC. If it
persists, unit KO.
Fatal. Clicking OK, the message
disappears and the IME is not ready.
Change USB port, change PC. If it
persists, unit KO.
Disconnect and reconnect USB cable.
Change USB port, change PC. If it
persists, unit KO.
HW Test Fault on System StartUp:
insufficient USB Power supply when
system switches on. Change USB
port, change PC. If it persists, unit KO.
Fatal. Clicking OK, the message
disappears and the IME is not ready.
Change USB port, change PC. If it
persists, unit KO.
Fatal. Clicking OK, the message
disappears and the IME is not ready.
Change USB port, change PC. If
persists, unit KO.
34
