Operator and Service Manual
Visualix eHD Book.indb 11
2) Intermediate Electronics unit (IME)
providing:
• power for the sensor
• timing and synchronisation of sensor signals
• signal pre-amplification
• analogue/digital signal conversion
• USB port interface
3) RINN intra-oral positioning device
Specifically designed to support the sensor and align it with the X-ray beam and with
the teeth of the upper and lower jaws.
Sensor cable
11
Printed on: , ; Printed by:
Gendex VisualiX eHD
TM
Indicator status (led)
USB Port
Doc #4519 986 19042 - February 2008
