Gendex VisualiX eHD
TM
6.1
Operator and Service Manual
Visualix eHD Book.indb 20
Installation of software driver
Before connecting the USB cable, carefully follow the procedure described below.
1) Install the diagnostic imaging software (such as VixWin) in the Personal Computer
following the installation and configuration procedures contained in the software
Operator Manual.
2) Check that the installed radiography imaging software (such as VixWin) is NOT run-
ning.
3) Insert the "Driver" disk supplied with the VisualiX system, containing the USB driv-
ers in the CD-ROM drive and follow the Windows "Guided Installation" instructions
provided.
If nothing happens after 10 seconds, then this means that the CD-Rom auto-run has
been disabled in the computer: it is necessary to manually launch the "Setup" file that
can be found in the main directory of the ActiveX Driver CD-ROM.
When you have completed the installation procedure, the icon representing the
software driver will appear in the Windows System Tray (also refer to section 7.2).
4) When the software installation is complete, connect the USB cable between the
computer and the IME.
USB cables permit connection or disconnection of the IME unit regardless of
whether the computer is on or off.
