Features and Functions of the GRAFIK Eye
Zone numbers
Zone raise/lower buttons
Zone LEDs display current
lighting zone levels
Shade column
Preset and raise/lower
buttons with integral LEDs
(maximum of 3 columns)
R
Hinged faceplate
1 2 3 4 5
{
Timeclock status button
Displays current
Used for programming
Hinged faceplate
Infrared receiver
For handheld remote use
QS System
®
Space for future
shade columns
6
timeclock info
OK button
fade time
USB type mini B input
GRAFIK Eye
Info screen
Displays status;
programming functions
OK
Master buttons
Temporarily raise and lower
lighting levels on unit
Lighting column
Scene buttons with integral
scene indicator LEDs
