NEC NC1000C Installationsanleitung

Vorschau ausblenden Andere Handbücher für NC1000C:
Inhaltsverzeichnis

Werbung

Quicklinks

Diese Anleitung herunterladen
DLP Cinema
Projector
®
Installation Manual
DLP Cinema
Projector
®
NC1000C
Model No.
NP-NC1000C

Werbung

Inhaltsverzeichnis
loading

Verwandte Anleitungen für NEC NC1000C

Inhaltszusammenfassung für NEC NC1000C

  • Seite 1 DLP Cinema Projector ® Installation Manual DLP Cinema Projector ® NC1000C Model No. NP-NC1000C...

  • Seite 2: Introduction

    DLP Cinema Projector Installation and Adjustment NEC Display Solutions, Ltd. Manual (This document) describes the procedures to install, adjust and maintain the projector (NC1000C) and peripheral devices. For safe and correct installation, adjustment and use of the projector, carefully read this document before installation.

  • Seite 3: Important Information

    NC1000C and keep the manual handy for future reference. This is a Class A product. In a domestic environment this The NC1000C (projector unit) is called the “projector”, and the product may cause radio interference in which case the user may be required to take adequate measures.
  • Seite 4 Important Information 9. Turn off the projector, and disconnect the power cable before moving the projector. 10. The cooling fan settings need to be configured when using the projector in a location at an altitude of approximately 5500 feet/1600 meters or higher. Refer to “About High Alti- tude mode”...
  • Seite 5 Important Information CAUTION: The power cable stopper (shown in below) is supplied with this projector. 7. Do not try to touch the air outlets on the projector during To prevent the power cable from coming loose, make sure normal projector operation as it is hot. that all the prongs of the power cable are fully inserted into the AC IN terminal of the projector before using the power Cleaning...
  • Seite 6 Important Information Handling the Battery A Lamp Characteristic • Take care when handling the battery, as it could cause fire, The projector has a discharge lamp for special purposes as injury, or damage to surrounding objects. a light source. - Do not short out, dismantle, or place batteries in a fire. A lamp has a characteristic that its brightness gradually • Dispose of used batteries according to your local decreases with age.
  • Seite 7 Email Address: contact@goldenduckgroup.com Email Address: info@nec-displays.com WEB Address: http://www.nec-display-solutions.com In North America Company Name: NEC Display Solutions of America, Inc. Address: 500 Park Boulevard, Suite 1100 Itasca, Illinois 60143, U.S.A. Telephone: +1 800 836 0655 Fax Line: +1 800 356 2415 Email Address: pjtechsupport@necdisplay.com...

  • Seite 8: Wichtige Informationen

    Wichtige Informationen Vorsichtsmaßnahmen: Lesen Sie sich dieses Handbuch bitte Maschinenlärminformations-Verordnung – 3. GPSGV, sorgfaltig durch, bevor Sie den NC1000C benutzen, und Der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger bewahren Sie das Bedienungshandbuch in greifbarer Nahe als gemäß EN ISO 7779.

  • Seite 9: Spannungsversorgung

    Wichtige Informationen 4. Wenn das Gerät direktem Sonnenlicht, Rauch oder Dampf WARNUNG: ausgesetzt wird, können interne Komponenten beschadigt werden. 1. Bedecken Sie die Linse nicht mit der mitgelieferten Lin- 5. Behandeln Sie Ihren Projektor vorsichtig. Fallenlassen oder senkape o.ä. wärend der Projektor eingeschaltet ist. Dies kann eine Verformung oder ein Schmelzen der Kappe starkes Schutteln...

  • Seite 10: Vorsichtsmasnahmen Zur Vermeidung Von Bränden Und Elektrischen Schlägen

    Wichtige Informationen • Biegen oder ziehen Sie das Netzkabel nicht übermäßig. 3. Schalten Sie den Projektor aus, ziehen Sie das Netzkabel • Legen Sie das Netzkabel nicht unter den Projektor oder ab und lassen Sie den ihn von einem qualifi - zierten Ser- unter einen anderen schweren Gegenstand.

  • Seite 11: Peripheriegeräte Und Verbindungskabel

    Wichtige Informationen 2. Reinigen Sie das Gehäuse regelmäßig mit einem Tuch. Bei • Auf der Leiterplatte der Haupteinheit ist eine Batterie mon- starker Verschmutzung verwenden Sie ein mildes Reini- tiert. Zerlegen Sie die Haupteinheit beim Entsorgen nicht, gungsmittel. Reinigen Sie das Gerät niemals mit starken und entfernen Sie nicht die interne Leiterplatte.

  • Seite 12: Bei Fragen, Die Sich Aus Unklaren Punkten Oder Reparaturarbeiten Ergeben

    Komponenten, wie beispielsweise der Lampe, Ihren Händler oder an die folgende Niederlassung. verkürzen. In Europa Firmenname: NEC Display Solutions Europe GmbH Adresse: Landshuter Allee 12-14, D-80637 Munich, Germany Telefon: +49 89 99699 0 Fax-Nummer: +49 89 99699 500 E-Mail-Adresse: info@nec-displays.com...
  • Seite 13 In Nordamerika Firmenname: NEC Display Solutions of America, Inc. Adresse: 500 Park Boulevard, Suite 1100 Itasca, Illinois 60143, U.S.A. Telefon: +1 800 836 0655 Fax-Nummer: +1 800 356 2415 E-Mail-Adresse: pjtechsupport@necdisplay.com Web-Adresse: http://www.necdisplay.com/ In China Firmenname: NEC Solutions (China) Co., Ltd.

  • Seite 14: Inhaltsverzeichnis

    Table of Contents Introduction ..................................2 Important Information ................................ 3 Wichtige Informationen ..............................8 1. Before Setting Up Your Projector ..........16 1-1. Clearance for Installing the Projector (English) ....................16 1-2. Freiraum bei der Projektorinstallation (Deutsch) ....................18 1-3. Selecting the lens unit ............................20 1-3-1.
  • Seite 15 Table of Contents 4-3-2. Lens Control ..............................68 4-3-3. Reset ................................69 4-3-4. Setup ................................72 4-3-5. Installation ..............................76 4-3-6. Memory ................................. 81 4-4. Title Setup ................................82 4-4-1. Preset Button ..............................82 4-5. Information ................................83 4-5-1. Lamp ................................83 4-5-2.

  • Seite 16: Before Setting Up Your Projector

    1. Before Setting Up Your Projector 1-1. Clearance for Installing the Projector (English) Allow ample clearance between the projector and its surroundings as shown below. Avoid installing the projector in a place where air movement from the HVAC is directed at the projector. Heated air from the HVAC can be taken in by the projector’s intake vent.
  • Seite 17 Before Setting Up Your Projector (2) For ceiling mounting: REMOTE RS-232 GP I/O Lens 70cm/27.6" or greater • The drawing shows the proper clearance required for the front, sides, back and bottom of the projector. NOTE • If suspending the projector 30 cm/12 inches away from the ceiling, allow ample clearance for all four sides and the under the projector.

  • Seite 18: Freiraum Bei Der Projektorinstallation (Deutsch)

    Before Setting Up Your Projector 1-2. Freiraum bei der Projektorinstallation (Deutsch) Achten Sie auf ausreichenden Freiraum zwischen dem Projektor und seiner Umgebung, wie unten gezeigt. Vermeiden Sie es, den Projektor an einer Stelle zu installieren, an der er den Luftströmungen von Klimaanlagen ausgesetzt ist. Die aufgeheizte Luft aus einer Klimaanlage kann vom Lüftungseinlass des Projektors aufgenommen werden.
  • Seite 19 Before Setting Up Your Projector (2) Bei der Deckenmontage: REMOTE RS-232 GP I/O Linse 70 cm oder mehr • Die Abbildung zeigt den ordnungsgemäßen Abstand für die linke, rechte, Vorder-, Rück- und Unterseite des HINWEIS Projektors. • Wenn Sie den Projektor 30 cm von der Decke entfernt installieren, achten Sie auf ausreichende Freiräume auf allen vier Seiten und unter dem Projektor.

  • Seite 20: Selecting The Lens Unit

    Before Setting Up Your Projector 1-3. Selecting the lens unit This section provides the guideline information on how to select a screen size, projector mounting position, and type of lens units, which is appropriate for your presentation purposes. Select the lens unit for your projector according to the environment in which it is installed.
  • Seite 21 Before Setting Up Your Projector Vertical moving screen mask Screen masks move vertically to adjust the screen. Screen mask Screen Screen mask...

  • Seite 22: Calculating The Lens Zoom Magnification To Use

    Before Setting Up Your Projector 1-3-2. Calculating the lens zoom magnification to use The lens zoom magnification required when installing the projector is calculated using the following method. (1) Calculate the lens zoom magnification for SCOPE projection (2) Calculate the lens zoom magnification for VISTA (FLAT) and HDTV projection (3) Select the lens that satisfies the zoom magnification calculated in (1) and (2).
  • Seite 23 Before Setting Up Your Projector Option lenses The lens units that can be attached to this projector are shown in the following table. MODEL Magnifying Lens memory support NP-9LS16Z1 1.63–2.03 NP-9LS20Z1 2.03–2.72 NP-9LS40Z 4.07–6.34  NP-9LS12ZM1 1.2–1.72  NP-9LS13ZM1 1.33–2.1 NP-9LS16ZM1 1.62–2.7 ...

  • Seite 24: Carrying The Projector

    Before Setting Up Your Projector 1-4. Carrying the projector When moving the projector, it should be carried by holding the handles on the base of the unit by 4 or more people. WARNING: When moving the projector, first turn off the power and always disconnect the power plug from the electrical outlet, and check that all of the connecting cables between equipment and the lenses have been removed.

  • Seite 25: Removing The Projector Covers

    Before Setting Up Your Projector 1-5. Removing the Projector Covers This section provides guideline information on how to mount and remove covers on the projector. Name of the cover Notch filter cover Side cover Front cover Filter cover (side) Lamp cover Filter cover (rear) • “Side cover”...

  • Seite 26: Removing And Mounting The Front Cover

    Before Setting Up Your Projector 1-5-1. Removing and Mounting the Front Cover When removing (mounting) the front cover, return the lens position to the center before turning off the projector power NOTE (page 78). If you do not return the lens position to the center, the lens may interfere and prevent you from removing (mounting) the front cover.
  • Seite 27 Before Setting Up Your Projector Remove the front cover. Lift up the cover slightly and then pull it towards you to remove it. This completes removing the front cover. To mount the cover, perform the removal procedure in reverse. Make sure that you do not forget to tighten the screw or to lock the key lock.

  • Seite 28: Removing And Mounting The Side Cover

    Before Setting Up Your Projector 1-5-2. Removing and Mounting the Side Cover Preparation: Phillips head screwdriver (No.2) and cover key (attached goods) Remove the filter cover (side). The filter cover is held in place by plastic clips (4 locations). Grasp the top and bottom edges of the cover and pull it towards you to remove it.
  • Seite 29 Before Setting Up Your Projector Remove the side cover. Pull the cover directly towards you to remove it. This completes removing the side cover. To mount the side cover, perform the removal procedure in reverse. Make sure that you do not forget to tighten the screws or to lock the key lock.

  • Seite 30: Removing And Mounting The Lamp Cover

    Before Setting Up Your Projector 1-5-3. Removing and Mounting the Lamp Cover Refer to the projector User’s Manual for details on how to remove and attach the lamp cover. 1-5-4. Removing and Mounting the Filter Cover Refer to the projector User’s Manual for details on how to remove and attach the filter cover. 1-5-5.

  • Seite 31: Setting Up Your Projector

    2. Setting Up Your Projector 2-1. Setup Procedure Set up the projector according to the procedure below. This chapter describes the installation of procedure until turning on of the power. • Step 1 Projector Installation (See page 32) • Step 2 Selecting the Power Cable (See page 33) Connecting the Power Cable (See Projector User’s Manual) • Step 3 Mounting the Lens Unit (See page 41)

  • Seite 32: Projector Installation

    Setting Up Your Projector 2-2. Projector Installation Move the projector to the projection position and install it corresponding to the screen and projection conditions. To correct the inclination to the right or left of the projector, use the level adjusters at 4 positions. You can extend the level adjuster to 35 mm at the maximum (Rotate it counterclockwise for extension).

  • Seite 33: Selecting The Power Cable (English)

    Setting Up Your Projector 2-3. Selecting the Power Cable (English) The power cable is not included with the projector. Refer to “2-3-1. AC Power Work Specifications” (page 34) and provide the necessary power cable. WARNING: Carefully read the contents described in this section before connection and connect the cables according to the proper proce- dure.

  • Seite 34: Ac Power Work Specifications

    Setting Up Your Projector 2-3-1. AC Power Work Specifications AC power supply equipment Do not use any voltage other than those shown below for the AC power supply connected to the projector. 100–130V AC, single phase, power, 50/60Hz 200–240V AC, single phase, power, 50/60Hz Breaker Connect the AC power supply from the power supply equipment of the building to the projector via a breaker.
  • Seite 35 Setting Up Your Projector AC power supply cable for the projector The projector is equipped with an IEC60320 C19 connector to connect an AC power supply cable. Ensure that the AC power cables that connect the connectors built into the projector to the AC power mains have the current capacities as shown below. Power supply voltage Projector input current Power cable current capacity...
  • Seite 36 Setting Up Your Projector China Plug Cable Connector GB2099 RVV 300/500 GB17465.1 Connector Dimensions of the connector of the power cable are shown below. -0.9 -0.7 ± +0.5 + 0.5 R3.5 min +0.5 Unit: mm...

  • Seite 37: Auswahl Des Netzkabels (Deutsch)

    Setting Up Your Projector 2-4. Auswahl des Netzkabels (Deutsch) Es wird kein Netzkabel mit dem Projektor geliefert. Nehmen Sie auf „2-4-1. Netzstrom-Spezifikationen“ (Seite 38) Bezug, und beschaffen Sie das notwendige Netzkabel. WARNUNG: Lesen Sie diesen Abschnitt vor dem Herstellen der Verbindungen sorgfältig durch, und schließen Sie die Kabel anhand der ordnungsgemäßen Verfahren an.

  • Seite 38: Netzstrom-Spezifikationen

    Setting Up Your Projector 2-4-1. Netzstrom-Spezifikationen Netzkabel Verwenden Sie für die Netzspannungsversorgung, die an den Projektorkopf angeschlossen ist, nur die unten angegebene Spannung. 100–130 V AC, eiphasig, 50/60Hz 200–240 V AC, eiphasig, 50/60Hz Ausschalter Verbinden Sie das Netzkabel mit der Netzversorgung via einen Abschalter. Die Ausschalterleistung hat abhängig von der Versorgungsspannung folgende Werte.
  • Seite 39 Setting Up Your Projector Netzkabel für den Projektor Der Projektor ist mit einem C19-Steckverbinder gemäß IEC60320 zum Anschließen des Netzkabels ausgestattet. Sorgen Sie dafür, dass die Netzkabel, die von den Steckverbindern am Projektor zum Netzanschluss führen, über die unten angegebenen Stromka- pazitäten verfügen.
  • Seite 40 Setting Up Your Projector China Stecker Kabel Steckverbinder GB2099 RVV 300/500 GB17465.1 Steckverbinder Die Abmessungen des Netzkabels sind unten angegeben. -0.9 -0.7 ± +0.5 + 0.5 R3.5 Min +0.5 Einheit: mm...

  • Seite 41: Mounting The Lens Unit

     NP-9LS40ZM1 4.07–6.34 • The other NEC optional lenses are not available on this model. NOTE • The projector and lenses are made of precision parts. Do not subject them to shock or excessive forces. • Remove the lens unit when moving the projector. If not, the lens could be subject to shock while the projector is being moved, damaging the lens and the lens shift mechanism.
  • Seite 42 Setting Up Your Projector Orient so that the connector on the lens unit is on the right side, then insert the lens into the projector. Orient so that the connector on the lens unit is on the right side Turn the lens clockwise. Rotate until it clicks to lock the lens unit into the projector.

  • Seite 43: Removing The Lens

    Setting Up Your Projector 2-5-1. Removing the lens Preparation: [1] Return to the center position. (page 78) [2] Turn off the main power and unplug the power cable. [3] Wait for the projector to cool sufficiently before removing the lens, before removing the front cover. (page 26) Rotate the lens counterclockwise while holding down the RELEASE LEVER.

  • Seite 44: Mounting The Lamp

    Setting Up Your Projector 2-6. Mounting the Lamp Refer to the projector User’s Manual for details on how to remove and attach the lamp. It is recommended that the lamps be replaced such that the difference between the lamp usage times is less than 2,000 hours because the brightness and color tone balance between the left and right sides of the screen will be lost if the difference between the lamp usage times exceeds 2,000 hours.
  • Seite 45 Setting Up Your Projector Remove the side cover. Side cover of the projector should be removed to mount the option board. For the procedure of removing the side cover, refer to “1-5-2. Removing and Mounting the Side Cover” (page 28). Remove the blocking panel from slot.

  • Seite 46: Make The Option Board Usable

    Setting Up Your Projector 2-7-1. Make the option board usable By registering the mounted option board to the slot, you can use option board by setting up the projector. This procedure is described for the example, when IMB (NP-90MS02) is mounted to slot. For the operation of the projector, refer to projector’s “Users Manual”.
  • Seite 47 Setting Up Your Projector Press the LEFT/RIGHT button to display “IMB” . Press the ENTER button. (*) is displayed to the selected item. Press the EXIT button several times. The projector exits the menu and goes back to the regular screen. If you press the EXIT button and then select “Yes”...

  • Seite 48: Projector Adjustment And Connecting

    3. Projector Adjustment and Connecting 3-1. Flow of Adjustment and Connecting Adjustment and Connecting of the projector accord to the procedure below. • Step1 Turning Your Projector On (See page 52) • Step2 Setting The Date and Time in the Projector (See page 53) • Step3 Setting the Projector Projection Method (See page 54) • Step4...

  • Seite 49: Recovering From Tamper Errors

    Projector Adjustment and Connecting 3-2. Recovering from Tamper Errors The tamper detection circuit is fitted in the projector. If any of the following actions is performed, an error message will be displayed on the LCD screen of the main unit control panel by tamper detection circuit.

  • Seite 50: Clearing Tamper Events

    Projector Adjustment and Connecting 3-2-1. Clearing tamper events Be sure to do this while the power of the projector is on (when Power-ON). If any tamper events have been detected by the tamper detection circuit of the projector main unit, clear the tamper events using the following procedure.
  • Seite 51 Projector Adjustment and Connecting • Step 1 “Clear the “Service Door Tamper” by using the buttons on the Control Panel.” Refer to “4-1-1. When You Use the Service Personnel Menu” (page 66) for details on logging into the projector with Advanced User or higher privileges using the buttons on the control panel.

  • Seite 52: Turning Your Projector On

    Projector Adjustment and Connecting 3-3. Turning your Projector On • Do not use the projector with the lens cap left attached, and do not attach the lens cap while the projector is operat- NOTE ing. The lens cap may become hot, causing them to deform or melt. • In the following instances, the power to your projector cannot be turned on even if you press the POWER button.

  • Seite 53: Setting The Date And Time In The Projector

    Projector Adjustment and Connecting Press the POWER button on the control panel of your projector three seconds or longer. Projector turns on. The POWER button indicator lights up green after the completion of activation. Press the LAMP ON/OFF button on the control panel for five seconds or longer. The lamp is turned on and the screen glows light about 15 seconds later.

  • Seite 54: Setting The Projector Projection Method

    Projector Adjustment and Connecting 3-5. Setting the Projector Projection Method The projection method can be changed in the projector menu. In the factory default settings, it is set to front (installed on a stand and projecting from the front of the screen). When installed on the ceiling, always set “Fan Tilt Setting”...
  • Seite 55 Projector Adjustment and Connecting Press the ENTER button. An (*) will be put on the selected fan operating mode. Press the EXIT button several times. The projector exits the menu and goes back to the regular screen. If you press the EXIT button and then select “Yes” and press the ENTER button on a regular screen, you are returned to user mode.

  • Seite 56: Adjusting The Lens

    Projector Adjustment and Connecting 3-6. Adjusting the Lens After attaching the lens unit, check that the lens type is set correctly. Furthermore, if you have attached a lens unit that supports the lens memory function, always execute calibration before adjusting the lens. After this, display the test pattern and adjust the screen size, focus and screen position with the lens unit.

  • Seite 57: Carry Out Calibration Of The Lens

    Projector Adjustment and Connecting 3-6-2. Carry out Calibration of the Lens If you have attached a lens unit that supports the lens memory function, always execute calibration before making adjustments. Preparation: • Check that the lens is attached correctly (page 41). • Set the lens type (page 56).

  • Seite 58: Adjusting The Screen Angle

    Projector Adjustment and Connecting 3-6-4. Adjusting the Screen Angle Preparation: Display the zoom/focus adjustment screen by using the following procedure. [1] Press the MENU button on the projector’s control panel. “Title Select” appears on the projector’s LC display. [2] Select “Configuration” menu using LEFT the LEFT/RIGHT button. [3] Press the DOWN button.

  • Seite 59: Replacing The Notch Filter

    Projector Adjustment and Connecting 3-7. Replacing the Notch Filter This projector is equipped with a notch filter that has been optimized for projection in a movie theater. The image can be made brighter by removing the notch filter. Note that the projector does not comply with the Color Gamut in the DCI standards in that case.
  • Seite 60 Projector Adjustment and Connecting Remove the notch filter. 1. Loosen the screw on the notch filter until it is free to spin ( ). The screw does not detach from the notch filter. 2. Gently pull up the notch filter and remove it ( ). Take the dummy bracket from the accessory box.
  • Seite 61 Projector Adjustment and Connecting Mount the notch filter cover to the projector. 1. Attach with the protrusions in the notch filter cover aligned with the holes in the projector. 2. Tighten the screw on the notch filter cover clockwise to fasten. This completes replacing the notch filter.

  • Seite 62: Connecting With The Image Input Port

    Projector Adjustment and Connecting 3-8. Connecting with the Image Input Port By installing option board to projector, you can add input port. Input port which can add to option board is listed below. For the connection diagram of projector and peripheral equipment, refer to Installation manual of option board. Option Board Image Input Port NP-90MS02 (Note)

  • Seite 63: Connecting The Various Control Terminal

    Projector Adjustment and Connecting 3-9. Connecting the Various Control Terminal For control, your projector comes with such ports as the PC control terminal and the Ethernet port (RJ-45). PC control terminal (RS-232) Use this terminal when controlling the projector in serial connection from a PC. Use a retail RS-232C straight cable for the connection between the projector and the computer.

  • Seite 64: Lcd Menu

    4. LCD Menu This chapter describes the menus displayed in the LCD screen on the projector’s control panel and their functions. For basic opera- tions of menus, refer to the projector’s operation manual. 4-1. List of Menu Menus in parentheses are menus for our service personnel. Normally, these menus cannot be used. If you are logged in to the projector with Installation privileges, you cannot use [FactoryDefault] - [LAN] (page 69).
  • Seite 65 LCD Menu Reference Main menu Submenu Description page (Title Setup) Preset Button Preset Button 1–16 Sets the title to be assigned to the preset buttons (<1> to <8> buttons). Information Lamp Output Displays the lamp output setting. Voltage Displays the lamp voltage value. Serial Displays the serial number of the lamp.

  • Seite 66: When You Use The Service Personnel Menu

    LCD Menu 4-1-1. When You Use the Service Personnel Menu To use the menu for service personnel, you need to input the passcode. This section describes how to display the passcode entry screen and how to enter the passcode. Refer to the Projector Manual for details on how to enter text. Press the MENU button for three seconds or longer.

  • Seite 67: Configuration

    LCD Menu 4-3. Configuration 4-3-1. Lamp Setup Adjust Adjust the lamp output (brightness). ← Displays the current output power value (%) when the lamp rated output is 100%. ← Displays the current power value (W). You cannot set the lamp output to below 80.5%. NOTE Lamp Mode Selects the lamp to use.

  • Seite 68: Lens Control

    LCD Menu 4-3-2. Lens Control Adjust the position, size, and focus of the projected screen. Press the ENTER button to switch the display between “Lens Position” and “Focus Zoom” adjustments. Press the EXIT button to return to a menu one level above. Lens Position Adjusts the position of the projected screen.

  • Seite 69: Reset

    LCD Menu 4-3-3. Reset Used when initializing settings and usage times. Some of the items are in the service personnel menu. Refer to “4-1-1. When You Use the Service Personnel Menu” (page 66) for details on how to use these. Item Service Personnel User...

  • Seite 70: Filter Cleaning

    LCD Menu Lamp Usage Resets the lamp usage time. When both lamp 1 and lamp 2 are replaced at the same time, reset the usage times of both lamp 1 and lamp 2. [1] Press the LEFT/RIGHT button to select the lamp to reset the usage time of, and then press the ENTER button. [2] Press the ENTER button in the “Lamp1”, “Lamp2”...
  • Seite 71 LCD Menu Fan Usage Resets the fan usage time. Press the ENTER button, then select “Yes” in the displayed confirmation screen, and then press the ENTER button to reset the fan usage time. ← Press the ENTER button to display the confirmation screen. Douser Count Resets the number of times the douser has been used.

  • Seite 72: Setup

    LCD Menu 4-3-4. Setup This menu is for service personnel. For the procedure to use it, refer to “4-1-1. When You Use the Service Personnel Menu” (page 66). Douser Setup Sets the douser open/close state. Request your dealer/distributor to perform the setting. ←...

  • Seite 73: Auto Key Lock

    LCD Menu Auto Key Lock Enables or disables Auto Key Lock. ← Displays the currently selected item with asterisk (*). ← Displays the setting. Enable Enables the auto key lock function. This applies the key lock automatically if you do not perform any operations from the main unit control panel for 30 seconds after entering the standby state.

  • Seite 74: Off Timer

    LCD Menu Off Timer Automatically turns off the projector power once the configured time has elapsed. The time until the power is turned off can be set in steps of 1 hour (up to a maximum of 24 hours). The timer starts from when the setting is applied by pressing the ENTER button. While the timer is running, the remaining time is displayed in the format “Left **.* H”.
  • Seite 75 LCD Menu When LCD Backlight is set to Disable, you can change the setting to Enable by long-pressing (3 seconds or more) the EXIT button and UP button.

  • Seite 76: Installation

    LCD Menu 4-3-5. Installation This menu is the service personnel menu. For the using service personnel menu, refer to “4-1-1. When You Use the Service Person- nel Menu” (page 66). Option Slot Configures the devices mounted in slot. This menu is active in standby mode only. Slot B is not available in this projector (displays as “Not Available”).
  • Seite 77 LCD Menu (If you selected Image Orient) ← Displays the currently selected item with asterisk (*). ← Displays the setting. Normal-F Front projection. With the projector installed on the pedestal, projection is executed from the front of the screen. Normal-R Rear projection.

  • Seite 78: Lens Center

    LCD Menu Lens Calibrate Performs calibration on lenses that support the lens memory function. Once you have attached a lens that supports the lens memory function, always execute calibration. This menu item is available only when the projector power is turned on. ←...

  • Seite 79: Fan Speed Mode

    LCD Menu Date/Time Use this to set the date and time on the projector. The internal clock in the projector uses coordinated universal time (UTC). This sets the time difference between the standard time in your region and UTC. ← Displays the currently setting with asterisk (*). ←...
  • Seite 80 LCD Menu Fan Noise Reduction Sets the cooling fan quiet mode. Quiet mode off (default value) Quiet mode on When turning quiet mode on, consult your dealer. NOTE...

  • Seite 81: Memory

    LCD Menu 4-3-6. Memory This menu is the service personnel menu. For the using service personnel menu, refer to “4-1-1. When You Use the Service Person- nel Menu” (page 66). The selected lens memory (lens adjustment value) and the content of the lamp memory (lamp mode and lamp output power value) can be overwritten with the current settings.

  • Seite 82: Title Setup

    LCD Menu 4-4. Title Setup This menu is the service personnel menu. For the using service personnel menu, refer to “4-1-1. When You Use the Service Person- nel Menu” (page 66). 4-4-1. Preset Button Use this button to set the titles to be assigned to the preset buttons (<1> to <8> buttons). You cannot assign the same title to several preset buttons.

  • Seite 83: Information

    LCD Menu 4-5. Information Displays the hours of lamp use, the version information and error codes. 4-5-1. Lamp Displays information relating to the lamp. Output Displays the lamp mode and lamp output power value (W). ← Selects the item to display. ←...

  • Seite 84: Preset Button

    LCD Menu 4-5-3. Preset Button Displays the titles assigned to the preset buttons (<1> to <8> buttons) on the projector’s control panel. ← Selects the preset button number whose contents you want to display. ← Displays the assigned title numbers. ←...

  • Seite 85: Version

    LCD Menu 4-5-6. Version Displays the version information about the projector, optional boards and IMB. System Displays the version information of the projector. ← Selects the item to display. ← Displays the version information. • Model • Serial No. • Release Package • Kernel • U-Boot • System Files...

  • Seite 86: Setup Date

    LCD Menu 4-5-8. Setup Date Displays the date when the projector was setup (starting date of the warranty period). The setup date is configured by using DCC. Refer to “Digital Cinema Communicator Installation Manual” for details. ← Displays the date when the projector was set up (starting date of the warranty period). 4-5-9.

  • Seite 87: Appendix

    5. Appendix 5-1. List of Registered Titles (when shipped from the factory)

  • Seite 88: Error Code List

    Appendix 5-2. Error Code List Please inquire your dealer/distributor about action to be taken for each error code. Error Code Error message Description GPSU(12V) Fail Power supply is abnormal. Lamp Unlit Lamp doesn’t light up. EEPROM R Fail EEPROM data read error is detected. EEPROM W Fail EEPROM data write error is detected.
  • Seite 89 Appendix Error Code Error message Description Fan13 Stop Precaution Fan13 Stop Precaution Fan14 Stop Precaution Fan14 Stop Precaution IMB:SD Tamper Terminate Terminated service door tamper event latched by IMB. * This message would be shown on Log, not on LCD. System Error ICP status error Self Test Error...
  • Seite 90 Appendix Error Code Error message Description IMB:Security Tamper Security tamper condition exists in IMB. IMB:Security Battery Event A Battery Tamper event has been detected with the IMB. IMB:Security Enclosure Not Armed IMB security not armed. IMB:Physical Marriage Tamper The IMB has detected a break of the Marriage with the projector.
  • Seite 91 Appendix Error Code Error message Description Fan17 Stop Fan17 has stopped. Fan18 Stop Fan18 has stopped. Fan19 Stop Fan19 has stopped. Fan20 Stop Fan20 has stopped. Fan15 Stop Precaution Fan15 Stop Precaution Fan16 Stop Precaution Fan16 Stop Precaution Fan17 Stop Precaution Fan17 Stop Precaution Fan18 Stop Precaution Fan18 Stop Precaution...

  • Seite 92: Remote Interlock Connector

    Appendix 5-3. Remote Interlock Connector This connector functions as safety device for the projector. The contacts are normally closed. When an abnormality occurs, the contacts open to immediately stop the projector (interlock state) (shipped with a shorting wire installed). By replacing the shorting wire with wiring and attaching it to the contacts, the projector can be immediately stopped remotely when an abnormality occurs in the projector.

  • Seite 93: Circuit Diagram

    Appendix Circuit diagram VCC +5V 1A fuse Shorting wire 1 390Ω/0.5W resistor 390Ω/0.5W resistor Shorting wire 2 Photocoupler Inside projector Interlock connector Connector no. Photocoupler ON/OFF Description — +5V supply ON/OFF Connects to the photocoupler anode inside the projector Connects to the photocoupler cathode inside the projector —...

  • Seite 94: Index
