Basler BIP-640c-dn Installationsanweisung Seite 9

Pin Function Description
3 Input Normally, the input is connected to ground via a switch as shown
in Figure 3 on page 10. As shown in the table below, the input will
be detected by the camera as active or inactive depending on
whether the switch is open or closed and whether the input mode
is set to normal or inverted.
See the camera user's manual for more information about setting
the input mode.
As an alternative, voltage from a device can be applied directly to
the input. As shown in Figure 4 on page 11, the voltage should be
applied directly to the input and not through a switch.
As shown in the table below, the input will be detected by the
camera as active or inactive depending on the voltage level
applied and whether the input mode is set to normal or inverted.
The area between +2.6 and +5.7 VDC is a transition zone and
should be avoided. The voltage applied to the input must not
exceed +24 VDC.
Table 2: Camera Pinout
Basler IP Camera
Switch Condition Input Mode
Open Normal
Closed Normal
Open Inverted
Closed Inverted
Voltage Applied Input Mode
0 to +2.6 VDC Normal
+5.7 to +24.0 VDC Normal
0 to +2.6 VDC Inverted
+5.7 to +24.0 VDC Inverted
Installation Guide
Input Detected As
Inactive
Active
Active
Inactive
Input Detected As
Active
Inactive
Inactive
Active
7
