Installation Guide
Pin Function
4 Output
Table 2: Camera Pinout
8
Description
The output employs an open collector transistor connected to
ground as shown in Figure 3 on page 10. As shown in the table
below, the output will or will not be connected to ground via the
transistor depending on the state of the output and whether the
output is set for the normal or the inverted mode.
See the camera user's manual for more information about setting
the output mode.
Note: If the output has been set to the inverted mode and you
restart the camera or you power it off and back on, the output will
be in the normal mode during the camera bootup process and will
return to the inverted mode once the bootup process is complete.
Output State
Inactive
Active
Inactive
Active
The maximum load is 100 mA and the maximum voltage is
+24 VDC.
If an inductive load such as a relay is used with the output, a
diode must be connected in parallel with the load as shown in
Figure 3.
Output Mode
Normal
Normal
Inverted
Inverted
Output Connected
to Ground
No
Yes
Yes
No
